Product Details:
|
| Products: | Stainless Steel Sheet | Grade: | 416 |
|---|---|---|---|
| Standard: | ASTM A240 | Thickness: | 0.3 - 4.0mm |
| Width: | 1000mm 1219mm | Brand: | TISCO BAOSTEEL POSCO |
| Service: | Cutting, Bending | Other Grade: | 301 304 304L 309S 310S 316L 316Ti 321 317L 347 410 420 430 2205 2507 904L 254SMO.etc |
| Surface: | 2B BA HL | Tolerance: | Within 5% |
| High Light: | Grade 416 Stainless Steel Sheet,ASTM A240 Stainless Steel Sheet,1500*6000mm Stainless Steel Sheet |
||
Cold Rolled Stainless Steel Sheet Grade 416 Stainless Steel ASTM A240 Thickness 0.3 - 4.0mm
Products Specification
| Products | 416 stainless steel sheet |
| Thickness | 0.3 - 4.0mm |
| Width | 1000mm 1219mm 1500mm or as request |
| Standard | ASTM A240/240M-18 |
| Brand | TISCO BAOSTEEL POSCO |
| Service | Cutting , bending , surface finishing |
| Other Grade |
201 202 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 444,2205 2507 904L 254SMO 253MA N08020 C276 625 600 800 825 monel 400 500.etc |
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm |
About 416 stainless steel
Grade 416 steel is a free-machining stainless steel with a machinability of 85%, highest of all stainless steels. With most of the free-machining stainless steels, the machinability can be improved by adding sulphur, which leads to the formation of manganese sulphide inclusions. Addition of sulphur also reduces the formability, weldability and corrosion resistance of 416 steels to below that of grade 410. Because of their high machinability and low cost, grade 416 steels are available in highly tempered, hardened or unhardened forms.
Martensitic steels with high hardness are manufactured using methods that require final hardening and tempering treatments. The corrosion resistance of these steels is lower than that of austenitic steels. Decrease in the ductility of martensitic steels at sub-zero temperatures, and strength at high temperatures due to over-tempering, are the two key factors that affect their operating temperatures.
Chemical Composition of 416 stainless steel
The chemical composition ranges of grade 416 stainless steels are given in the following table:
Table 1 - Composition ranges for grade 416 stainless steels
| Grade | C | Mn | Si | P | S | Cr | Mo | |
| 416 |
min. max. |
- 0.15 |
- 1.25 |
- 1 |
- 0.06 |
0.15 - |
12 14 |
- 0.6 |
Mechanical Properties of 416 stainless steel
The table below provides the mechanical properties of grade 416 stainless steels:
Table 2 - Mechanical properties of grade 416 stainless steels
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) |
Elongation (% in 50mm) |
Hardness Brinell (HB) |
Impact Charpy V (J) |
| Annealed * | 517 | 275 | 30 | 262 | - |
| Condition T ** | 758 | 586 | 18 | 248-302 | - |
| 204 | 1340 | 1050 | 11 | 388 | 20 |
| 316 | 1350 | 1060 | 12 | 388 | 22 |
| 427 | 1405 | 1110 | 11 | 401 | # |
| 538 | 1000 | 795 | 13 | 321 | # |
| 593 | 840 | 705 | 19 | 248 | 27 |
| 650 | 796 | 670 | 17.5 | 253 | 38 |
* Annealed properties are typical for Condition A of ASTM A582.
** Hardened and tempered Condition T of ASTM A582 - Brinell hardness is specified range, other properties are typical only.
# Tempering of this steel at temperatures of 400 to 580°C should be avoided due to low impact resistance.
Contact US
Grade Specification Comparison of 416 stainless steel
The following table outlines the grade comparisons for 416 stainless steels:
Table 4 - Grade specifications for grade 416 stainless steels
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 416 | S41600 | 416S21 | 56AM | 1.4005 | X12CrS13 | 2380 | SUS 416 |
