Specification
| Product Name |
Stainless steel sheet / plate |
| Type |
Cold Drawn or Hot Rolled |
| Thickness |
0.1-300mm |
| Width |
1000, 1219, 1500, 2000, 2500, 3000mm etc. |
| Length |
1000, 1500, 2438, 3000, 5800, 6000, 9000, 12000mm etc. |
| Standard |
ASTM JIS AISI GB DIN EN |
| Surface Finished |
BA, 2B, NO.1, NO.4, 4K, HL, 8K |
| Application |
It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture,
and ship components.
It also applies to food and beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts,
springs, and screen mesh etc. . |
| Certification |
CE, ISO, SGS, BV |
| Technique |
Hot rolled or cold drawing |
| Edge |
Mill Edge / Slit Edge |
| Quality |
SGS Inspection |
| Grade(ASTM UNS) |
201 202 301 304 304L 321 316 316L 317L 347H 309S 310S 904L S32205 2507 254SMOS 32760 253MA N08926 etc. |
| Grade (EN) |
1.4301, 1.4307, 1.4541, 1.4401, 1.4404 ,1.4571, 1.4438, 1.4539, 1.4547, 1.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876,
2.4858, 2.4819 |
| Main market |
Asia/Europe/ South America |
| Brand Name |
TISCO |
| Delivery time |
Within 7-10 Working Days |
| Port of Loading |
Shanghai China |
| Price Terms |
CIF CFR FOB EX-WORK |
| Export Packing |
Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package |
| Supply Ability |
5000 Ton/Tons per Month |
| Payment Terms |
T/T L/C and Western Union etc. |
Product Display
We have stainless steel plate, diamond plate, 2B & 2D stainless steel sheet, stainless steel polished sheet, stainless steel flat &expanded sheet, and perforated stainless steel sheet and other plates.
|
A.I.S.I.
U.N.S.
|
Characteristics
|
End-Use
|
|
301
S30100
|
Able to attain tempers from 1⁄4 through full
hard, extra full hard by cold rolling.
Withstands severe forming in annealed
condition.
|
Kitchen sinks, Automotive wheel
covers. Toaster springs, Seat belt
buckles
|
|
303
S30300
|
Highest machinability rating among the
300 series. Forming and welding are not
recommended.
|
Nuts and bolts, threaded rods,
Fittings.
|
|
304
S30400
|
Excellent corrosion resistance and suitable
for deep drawing applications when Nickel
content is increased. Carbon content
.08% max.
|
Food Industry, Chemical Industry,
Deep drawing applications, Aesthetic
application.
|
|
304L
S30403
|
Same characteristics as 304 with a lower
carbon content .03% max. Used when
post weld annealing is impossible. The
lower carbon content reduces carbide precipitation in the welded zone.
|
Large fabricated equipment.
|
|
316
S31600
|
Molybdenum bearing alloy with better
overall corrosion resistance than 304 and higher creep strength at elevated temperatures.
|
Marine coastal environments, Pulp
and paper industry, Chemical and
petrochemical Industry
|
|
316L
S31603
|
Same characteristics as 316 with a lower Carbon content .03 max. Good corrosion resistance in high temperature intermittent
service. Used when post weld annealing is impossible. The lower carbon content
reduces Carbide precipitation in the welded zone.
|
Large fabricated equipment.
|
|
317L
S31703
|
Higher Molybdenum content than 316 for
better corrosion resistance. Carbon con
tent .03% max.
|
Corrosive environments. Chemical
and petrochemical industries.
|
|
309
S30900
309S
S30908
|
Heat resisting alloy with good corrosion
resistance. High tensile and creep
strengths as well as at elevated temperatures. 309S has a lower Carbon content
.03 max.
|
Furnace parts, Baffles, Cement kiln
chains. Exhaust manifold butterfly
valves.
|
|
310
S31000
310S
S31008
|
Improved characteristics over 309 and
better scaling resistance in intermittent
elevated temperatures. Grade 310 has a
low co-efficient of expansion.
|
Furnace parts, Carburizing boxes,
Heat exchangers, Oil burner parts.
|
Why Choose Us
Manufacturing Technique
Stainless steel plate process: if be annealed stainless steel should be used chemical NG - 9-1 to black, have the oil with NZ - B in addition to the first oil to oil - water - electrochemical finishing polish king (directly using the fluid as working fluid,
temperature of 60 ~ 80 ºC, hang anode workpiece, current Da: 20 to 15 a/dm2, cathode - to lead antimony alloy antimony (including 8%) time: 1 ~ 10 minutes, cast light) - water - 5 ~ 8% hydrochloric acid membrane back (at room temperature: 1 ~ 3 seconds) to water washing, blow dry.
About US
Good Quality Makes Us Different!
* All stainless steel plate products are produced by ISO9001 certified mill !
* All stainless steel plate products are EN10204:2004 3.1 Certified !
* Non-destructive Testing Report are available if required !
* Heat Treatment Report are available if required !
* Mechanical Testing Report are available if required !
MITTEL is located in Wuxi, Jiangsu Province . It is one of stainless steel bases in China. Our factory covers an area of 80,000 square meters. We are one of the Jiangsu stainless steel manufacturers.
Our main products including stainless steel pipe ,stainless steel plate , stainless steel bar , stainless steel coil , stainless steel round bar , Stainless steel square tube ,stainless i-beam , stainless angle steel , stainless steel channel , Hastelloy alloy , etc . Our company has the most advanced production equipment which guarantee the most advantageous product quality . Based on highly quality products and best service , we have develop clients all round the world ,our products are widely used in industry in USA ,Germany ,India ,Iran , Dubai , Iraq , Vietnam , Ireland , Singapore ,and so on .The specifications are complete and the price is favorable. Our company can order various non-standard specifications on behalf of customers , special material steel products, can be delivered to your door, ordering quickly.
Service and commitment:
Service three guarantees: guarantee quality, guarantee time, guarantee quantity.
Service tenet: strong strength, high quality products, low price, first-class service.
Solemn promise: Reply to the trust of the old and new customers with the best products, the best quality, the lowest price and the most perfect service.
Operating principles: customer first, Excellent quality, great variety, and reasonable price.
MITTEL . will serve the majority of users with good reputation, strong strength, high quality products and low price. I would like to express my heartfelt thanks to the old and new friends and customers who have always cared, supported and helped the company! And sincerely hope to establish long-term cooperative relations with them, mutual benefit and common development .
Product Application
Stainless steel sheet & SS plate provide a low maintenance, corrosion resistance solution for a variety of industrial
applications. Some of the typical uses for stainless steel include:
* Food Processing & Handling
* Storage Tanks
* Heat Exchangers
* Electrical Enclosures
* Chemical Process Vessels
* Conveyors
* Architectural & Construction
* Marine Parts & Equipment
Packing & Delivery
|
Package
|
Standard export seaworthy package,suit for all kinds of transport, or as required.
|
|
Water-proof Paper + Edge protection + Wooden Pallets
|
|
Bulk Size
|
Any size
|
|
Loading Port
|
Tianjin, Xingang Port, Qingdao,Shanghai, Ningbo, or any China Seaport
|
|
Container
|
1*20ft container load Max. 25 Ton, Max. length 5.8m
|
|
1*40ft container load Max. 25 Ton, Max. Length 11.8m
|
|
Delivery Time
|
7-15 days or according to the order's quantity
|
FAQ
Q1. Where is your factory ?
A1: Our company's processing center is located in Jiangsu, Wuxi, China.
Which is well equipped with kinds of machines, such as laser cutting machine,mirror polishing machine and so on.
We can provide a wide range of personalized services according to the customers' needs.
Q2. What are your company's main products ?
A2: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q3. How do you control quality ?
A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.
Q4. What are the advantages of your company ?
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q5. How many coutries you already exported ?
A5: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt,Turkey, Jordan, India, etc.
Q6. Can you provide sample ?
A6: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7days.
