Product Details:
|
| Steel Grade: | SAE1045 | Alloy Or Not: | Non-alloy |
|---|---|---|---|
| Technique: | Hot Rolled,Cold Drawn | Type: | Flat Bar |
| Standard: | ASTM,DIN,AISI | Shape: | Flat |
| Length: | 1--12m | Delivery Condition: | Annealed |
| Highlight: | dia 3mm cold drawn round bar,sae1045 cold drawn round bar,dia 150mm cold drawn bright bar |
||
|
Product Name |
Cold Drawn steel bar | |||||
|
Technique |
Cold Drawn | |||||
|
Type |
Low Carbon Steel, Medium Carbon Steel | |||||
|
Place of Origin |
JIANGSU, China(mainland) | |||||
|
Grade |
GB |
DIN | JIS | ASTM/SAE/AISI | BS | |
|
20# |
C22/CK22 | S20C | 1020 | IC22 | ||
|
45# |
C45/CK45/1.0503 | S45C/S48C | 1045 | 060A42/060A47 | ||
|
Q235B |
S235jr | SS400 | A36 | S235jr | ||
|
Q345B |
SM490 | S355JR | ------ | S355JR | ||
|
Section Shape |
Round, square, hexagonal, flat, deformed | |||||
|
Surface |
Bright | |||||
|
Specifications |
Round Bar |
4mm-80mm | ||||
|
Flat Bar |
Length: 20-150mm | |||||
| Width: 3-80mm | ||||||
|
Square Bar |
4*4mm-80*80mm | |||||
|
Hexagon bar |
4-80mm | |||||
|
Deformed |
Special drawings | |||||
|
Length |
2m, 4m, 5.8m, 6m or as required | |||||
|
delivery condition |
cold drawn , anneal or not | |||||
|
Payment Terms |
T/T, L/C | |||||
|
Package |
Bundled, wooden box for export standard package | |||||
|
Price Terms |
EXW, FOB, CIF,CFR | |||||
|
Delivery Time |
Normally according to the order quantity | |||||
|
Container Size |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
|||||
| Chemical composition %: | |||||||
| C | Si | Mn | S | P | Cr | Ni | Cu |
| 0.4-0.45 | 0.17-0.37 | 0.70-1.00 | ≤0.035 | ≤0.035 | ≤0.25 | ≤0.30 | ≤0.25 |
| mechanical properties: | ||||||
| Tensile strength σb (Mpa) |
Yield strength σb (Mpa) |
Elongation σb (%) |
reduction of area ψ (%) |
Hardness No heat treatment |
Impacting Energy Akv (J) | Notched bar impact strength αkv (J/cm2) |
| min | min | min | min | max | min | min |
| 540(55) | 315(32) | 20 | 45 | 217HB | 63 | 78(8) |
| WE CAN OFFER PRODUTS LIKE THESE | |
| Round Bar | Diameter3-800mm or as required |
| AngleBar | Size:3*20*20mm-12*100*100mm as required |
| Square Bar | Size:4*4mm-100*100mm as required |
| Flat Bar | TK:2-100 width:10-500mm as required |
| Hexagonal Bar | Size:2-100mm as required |
|
GB |
C | Si | Mn | S | P | Cr |
|
20 |
o.17-0.23 | 0.17-0.37 | 0.35-0.65 | Max0.035 | Max 0.035 | Max0.25 |
|
45 |
0.42-0.5 | 0.17-0.37 | 0.5-0.8 | max 0.035 | max 0.035 | max 0.25 |
|
Q235b |
0.12-0.22 | max 0.3 | 0.3-0.65 | max 0.05 | max 0.045 | max0.02 |
|
Q345b |
Max 0.2 | Max0.55 | Max1.7 | Max0.035 | Max0.04 | Max0.3 |
![]()
![]()
Q: How about the MOQ? If my first order qty is small, will you accept?
A: We would like to do our best to support your trial order qty, so even 1 pc or 1 kg is ok to start cooperation; because we have confidence to move on second order with your esteemed company.
Q: What is your payment terms ?
A: Commonly two payment term for new customers: 1) 30% T/T as deposit , 70% balance against B/L copy; 2) 100% Irrevocable L/C at sight;If you need any other terms, pls feel free to contact us too, we will try our best.
Q: How long is your delivery time?
A: Our daily inventory is more than 8000 tons, so for common product size, just need 5 days from stocks; if the special size from new production, delivery 7 days.
Q: How about the samples ? is it free or extra fees?
A: Yes, we would like to supply the samples before order; if the samples from stock, it will be free; if the samples from new production, we will charge some reasonable cost, but this amount will be deducted from your first order invoice.
Q: How to control and guarantee your shipment quality?
A: 1) All our factories are ISO9001, CE certified facility; 2) World famous origin mills as TISCO, Baosteel. 3) Ex factory inspection by our own laboratory. 4) SGS/BV Third party inspection before delivery.
