ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed

ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed
ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed

Large Image :  ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed

Product Details:
Place of Origin: China Jiangsu
Brand Name: TISCO BAO STEEL ZPSS LISCO
Certification: SGS ISO MTC
Model Number: 436L
Payment & Shipping Terms:
Minimum Order Quantity: 200KGS
Price: 1.65 USD/KG
Packaging Details: Wodden Pallet
Delivery Time: 10 Days
Payment Terms: L/C, T/T
Supply Ability: 300000KGS

ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed

Description
Material: SUS436L Color: 2B /2D NO.1 Or Customized
Size: Customized Size,as Your Request Feature: Corrosion Resistance High Temperature
Thickness: 1-3mm,3-10mm Or Customized Width: 1000-1500mm
Length: 2000-6000mm
High Light:

436l 3mm stainless steel sheet

,

2d finished 3mm stainless steel sheet

,

astm a240 brushed stainless steel sheet

Stainless Steel 436 / 436L Sheets Specifications:


Specifications ASTM A240, ASME SA240
Dimensions ASTM, ASME and API
Standard JIS, AISI, ASTM, GB, DIN, EN, etc.
Surface 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc.
Finish Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc.



Grade Specifications for Stainless Steel 436 / 436L Sheets



STANDARD WERKSTOFF NR. UNS JIS
SS 436 1.4536 S43600 SUS 436
SS 436L SUS 436L



Chemical Properties of SS 436 / 436L Sheets

Grade Fe Cr Ni Mo Mn Nb Si Ti Ta C P S
SS 436 81.3 16 1 1 0.5 0.5 0.12 0.040 0.030
SS 436L 80.49 17.3 0.3 1 0.3 0.3 0.3 0.01

Mechanical Properties of SS 436 / 436L Sheets

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation Hardness
0.28 lbs/in3 7.74 g/cm3 2600 – 2750 ° F (1427 – 1510 °C) 77 KSI min (531 MPa min) 53 KSI min (365 MPa min) 40 % Rb 89 max
0.28 lbs/in3 7.74 g/cm3 2600 – 2750 ° F (1427 – 1510 °C) 441-517 MPa 64000-75000 psi (Metric) 276-345 MPa 40000-50000 psi (Imperial) 28-35% 74-85





Product name Prime quality ASTM A240 AISI 436 2B Finish cold rolled Stainless Steel Sheets from TISCO ZPSS
Materials Mill TISCO,ZPSS
Surface 2B
Standard ASTM A240
Grade 400 series
Technical treatment Cold Rolled
Thickness 1mm
Width 1000mm
Length 2000mm
Application Escalator, Elevator, Production tools, Kitchen appliances, freezers, cold rooms,Auto Parts,Machinery and Packaging,Equipment and Medical devices,Transport system
Package

In bundles, packed with wooden pallet and can be also according to the regulations and customer’s requests.



Type 436 is a 1% molybdenum-alloyed ferritic stainless steel with medium chromium content. It is suitable for use in many corrosive environments, like for instance in the cold end of automotive exhaust systems. Because of its titanium alloying, Type 436 can be welded in all dimensions without becoming susceptible to intergranular corrosion.

SPECIFICATIONS

Grade

Tensile Strength,

min.



Yield Strength,B

min



Elongation in

2 in.(50mm)

Cold

Bend

436 ksi MPA kis MPA min,% 180
65 450 35 240 22



Chemical Component(%) (AISI 436)
C ≤0.025
Cr 16.00-19.00
Mn ≤1.00
P ≤0.040
S ≤0.030
Si ≤1.00
Mo 0.75-1.00
N 0.025



ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed 0ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed 1ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed 2ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed 3

ASTM A240 SUS436L Grade 3mm Stainless Steel Sheet 2D Finished Brushed 4
