Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube

Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube
Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube
Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube

Large Image :  Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube

Product Details:
Place of Origin: China
Brand Name: DELTA
Certification: SGS ISO MTC
Model Number: S32205 S22053
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 4.85 USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube

Description
Application: Industry,boiler,Chemical Standard: GB,DIN,ASTM,JIS,AISI
Steel Grade: Duplex Stainless Steel Type: Seamless
Thickness: 1-50mm Length: 3000mm~6000mm,Customer Request
Shape: Round Outer Diameter: 10 - 506mm
Technique: Hot Rolled Service: Cutting
High Light:

s31803 stainless steel seamless tube

,

s32205 stainless steel seamless tube

,

2205 duplex stainless steel pipe

Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Pipe / Duplex Stainless Steel Pipe



Our company is special in selling all kinds of duplex stainless steel pipe with standard ASTM A789 SA789 S31803 S32205 2205 Duplex Tubes and ASTM A790 SA790 S31803 S32205 2205 Duplex Pipes.



Dimension Welded: 1/2″~72″
Seamless: 3/8″~16″ / SCH 5S SCH10S, 40S, STD, XS, SCH80S
Grade UNS S31803, S32205, S32750, S32760, S32304, 1.4462, 1.4410, 1.4501, 1.4362 etc.
Standard ASTM A789, ASTM A790, ASME SA 789 SA 790, EN 10216-5, EN/DIN17455-2, EN17456-2 etc.





Duplex Steel is featured with structure of two phases (α and γ) and has characteristics of both ferritic and austenitic stainless steel. It has good corrosion resistance and high strength. It is alloyed with 18%-28% Cr and 3%-10% Ni in the condition of low C. Some steels also contain the alloy elements such as Mo, Cu, Nb, Ti and N, etc. Comparing with ferritic stainless, duplex stainless steel has higher plasticity, ductility and better intergranular corrosion resistance and weldability. It keeps same 475°C brittleness with ferritic stainless and high thermal conductivity. Duplex has improved yield strength, resistance to intergranular corrosion, stress corrosion, corrosion fatigue and abrasion & corrosion compared with austenitic stainless steel.

Alloy 2205 UNS S32305/S31803 is a 22% chromium, 3% molybdenum, 5-6% nickel, nitrogen alloyed Duplex Stainless Steel Pipe with high general, localized, and stress corrosion resistance properties in addition to high strength and excellent impact toughness.

Alloy 2205 provides pitting and crevice corrosion resistance superior to 316L or 317L austenitic stainless steel tube in almost all corrosive media. It also has high corrosion and erosion fatigue properties as well as lower thermal expansion and higher thermal conductivity than austenitic.

2101 is a low nickel, lean duplex stainless steel possessing both superior strength and chloride stress-corrosion cracking resistance when compared to 300 series stainless steel.

2304 A lean austenitic-ferritic duplex stainless steel with general corrosion resistance similar to 316, but with yield strength nearly double that of austenitic stainless steel.

S31803 and S32205 are standard duplex stainless steel. A nitrogen, molybdenum enhanced austenitic-ferritic duplex stainless steel with general corrosion resistance similar to 904L, but with a yield strength nearly double that of austenitic stainless steel.

2507 (PREN 40-45), with 25-26 Cr and increased Mo and N compared with the 25Cr grades. A super austenitic-ferritic duplex stainless steel with exceptional strength and corrosion resistance ideal for chemical process, petrochemical, and seawater applications.



Chemical Composition of 2205 duplex stainless steel



Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube 0



Standard Informations



ASTM A789 – 17 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel for General Service

ASTM A790 – 16 Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe

ASTM A923 Standard Test Methods for Detecting Detrimental Intermetallic Phase in Duplex Austenitic/Ferritic Stainless Steel
ASTM A928 A928M Standard Specification for Ferritic/Austenitic (Duplex) Stainless Steel Pipe Electric Fusion Welded with Addition of Filler Metal
ASTM A789 (ASME SA789) Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
ASTM A790 (ASME SA790) Standard Specification for Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
ASTM A923 Standard Test Methods for Detecting Detrimental Intermetallic Phase in Duplex Austenitic/Ferritic Stainless Steel
ASTM A928 Standard Specification for Ferritic/Austenitic (Duplex) Stainless Steel Pipe Electric Fusion Welded with Addition of Filler Metal
EN 10216-5 Seamless steel tubes for pressure purposes
GB/T 21832-2008 Austenitic–Ferritic(duplex) grade stainless steel welded tubes and pipes
GB/T 21833-2008 Austenitic-Ferritic (duplex) grade stainlee steel seamless tubes and pipes



Duplex Stainless Steel Pipe Specification

Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube 1Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube 2Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube 3Duplex 2205 / 1.4462 / S31803 / S32205 Stainless Steel Seamless Tube 4
