Hot Rolled 304 EN 10088 1.4319 6mm Stainless Steel Plate

Hot Rolled 304 EN 10088  1.4319 6mm Stainless Steel Plate
Hot Rolled 304 EN 10088  1.4319 6mm Stainless Steel Plate Hot Rolled 304 EN 10088  1.4319 6mm Stainless Steel Plate Hot Rolled 304 EN 10088  1.4319 6mm Stainless Steel Plate Hot Rolled 304 EN 10088  1.4319 6mm Stainless Steel Plate

Large Image :  Hot Rolled 304 EN 10088 1.4319 6mm Stainless Steel Plate

Product Details:
Place of Origin: Shanxi
Certification: ISO
Model Number: 301
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: USD1800-2300/Ton
Packaging Details: Wooden pallet ( Fumigation treatment ), standard export packaging or as per customer's request
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T
Supply Ability: 2000 T/month

Hot Rolled 304 EN 10088 1.4319 6mm Stainless Steel Plate

Description
Brand Name: Tisco Material: Stainless Steel
Standard: ISO Type: Plate
Application: Chemical Industry Edge: Mill /Slit
High Light:

ISO 304 polished stainless steel plate

,

304 6mm Stainless Steel Plate

,

1.4319 6mm Stainless Steel Plate

Hot Rolled 304 Stainless Steel Plate 3.0 - 16.0mm SS Plate EN 10088 1.4319 Stainless Steel



Product Name
301 stainless steel plate
Standard
ASTM, EN
Brand TISCO
Certificate
MTC according to EN 10204-3.1


Specification

Cold rolled sheet

Thickness: 0.4 - 2.5mm

Size:1219x2438mm

Hot Rolled plate:
Thickness:  3.0 - 16.0mm
Size: 1500 x 6000mm

Surface
Hot Rolled: No.1
Cold Rolled: 2B,
Trade terms
Ex-Work, FOB/CFR/CIF
Payment terms
T/T, L/C at sight, Western Union,etc.
Delivery Time
5-8 days after receive the deposit.
Packing
Water proof film coated, standard export package or as required.
Port of shipment
201, 202, 301, 302, 304, 304L, 316, 316L, 310S, 310,405, 409, 430, 410, 420, 440A,904l, etc



Stainless steel grade 301 is usually supplied in the form of strips and wires, with a tensile strength of up to 1800 Mpa, to produce tempers ranging from 1/16 Hard to Full Hard. By subjecting grade 301 to controlled analysis it is capable of retaining sufficient ductility even in ½ hard conditions. This form of grade 301 may be used in aircraft, rail car components and architectural structures. Tempers of this grade, ranging from ¾ to full hard, may be used in applications requiring high wear resistance and spring features with simple form designs.

Grade 301L, which is the low carbon form of grade 301, is the ideal choice for applications that require good ductility. Grade 301LN is another variant. This contains a higher percentage of nitrogen and exhibits a higher work harden rate compared to standard 301. Only grade 301 is specified in ASTM A666. 301L and 301LN are represented by other conventions. Grade 301L is represented by JIS G4305 and 301LN by EN10088-2 as grade 1.4318.





Composition

Composition ranges of stainless steel grade 301 are tabulated below.

Table 1 - Composition ranges for 301 grade stainless steel

Grade C Mn Si P S Cr Mo Ni N

301

ASTM A666

min.

max.

-

0.15

-

2.0

-

1.0

-

0.045

-

0.030

16.0

18.0

-

6.0

8.0

-

0.10

301L

JIS G4305

min.

max.

-

0.03

-

2.0

-

1.0

-

0.045

-

0.030

16.0

18.0

-

6.0

8.0

-

0.20

1.4318/301LN

EN 10088-2

min.

max.

-

0.03

-

2.0

-

1.0

-

0.045

-

0.015

16.5

18.5

-

6.0

8.0

0.10

0.20

Mechanical Properties

The mechanical properties of grade 301 stainless steels are listed in the table below. The bend test is obtained around a diameter of the bend factor multiplied by the steel thickness.

Table 2 - Mechanical properties of 301 grade stainless steel

Grade 301 Temper ASTM A666 Tensile Strength (MPa) min. Yield Strength 0.2% Proof (MPa) min. Elongation (% in 50mm) (thick.>0.76mm) min. Bend Test (thickness > 1.27mm)
Bend Angle (°) Factor
Annealed 758 276 60 - -
1/16 Hard 620 310 40 180 1
1/8 Hard 690 380 40 180 1
1/4 Hard 862 514 25 90 2
1/2 Hard 1034 758 18 90 2
3/4 Hard 1205 930 12 90 3
Full Hard 1276 965 9 90 5

Applications

Some of the typical applications of grade 301 stainless steels are listed below:

  • Making rail car structural components
  • Air frame sections
  • Highway trailer components
  • Automotive wheel covers
  • Wiper blade clips and holders
  • Stove element clips
  • Screen frames
  • Toaster springs
  • Curtain walls
