ASTM A276 Grade 316L 310S Stainless Angle Bar

Large Image : ASTM A276 Grade 316L 310S Stainless Angle Bar

Product Details:

Place of Origin:	CHINA
Brand Name:	GMS
Certification:	ISO 9001
Model Number:	201 304 316L 310S

Payment & Shipping Terms:

Minimum Order Quantity:	100 kgs
Price:	1500 USD/Ton
Packaging Details:	packing for export
Delivery Time:	5 - 8 days
Payment Terms:	T/T, Western Union
Supply Ability:	300 Ton/Month

Contact Now

ASTM A276 Grade 316L 310S Stainless Angle Bar

Description

Products:	Stainless Steel Angle Bar	Grade:	201 304 316L 310S
Type:	Angle Bar	Length:	6m
Other Material:	Channel Bar, Flat Bar,round Bar.etc	Company Type:	Factory
Deliver Time:	Within 10 Days	Service:	Cutting
Highlight:	310S Stainless Angle Bar , 316L Stainless Angle Bar , ASTM A276 Stainless Angle Bar

ASTM A276 Grade 201 304 316L 310S Stainless Steel Angles / Equal Stainless Steel Angle Bar

Commodity	stainless steel angle bar
Size	20mmx20mmx3mm~150mmx150mmx12mm
Length	6m, or as customized
Surface	hot rolled
Application	Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields
Delivery Time	5 - 8 days, according to quantity
Price Terms	FOB/ CFR/ CIF
Package	Export standard package, or as per customers' requirement
Other Products	stainless steel channel bar,stainless steel round bar, stainless steel flat bar, stainless steel hexagon bar

Element (Wt.%)

	C	Mn	P	S	Si	Cr	Ni	N	Mo	Ti
201	0.15max	5.50-7.50	0.06max	0.030max	1.00max	16.00-18.00	3.50-5.50	0.25max	-	-
304	0.08max	2.00max	0.045max	0.030max	1.00max	17.50-19.50	8.00-10.50	0.10max	-	-
316L	0.03max	2.00max	0.045max	0.030max	1.00max	16.00-18.00	10.00-14.00	-	2.00-3.00	-

Mechanical Property

Material Item	Tensile Strength (MPa)	Yield Strength (MPa)	Extension	Hardness (HV)	Density
201	≥520	≥275	≥40%	<253	7.93g/cm³
304	≥520	≥205	≥40%	≤200	7.93g/cm³
316L	≥480	≥177	≥40%	≤200	7.98g/cm³

Our Products Detail informations

Stainless steel angle bar	Grade:201 304 316L 310S.etc Size:30303mm-15015010mm x 6m length Type: equal angle
Stainless steel channel bar	Grade:201 304 316L 310S.etc Size:4# - 20# Type: U channel
Stainless steel round bar	Grade:201 304 316L 310S 321 2205 2507 904L.etc Size:4 - 350mm Type: black bar, bright bar
Stainless steel hexagon bar	Grade:201 304 316L 410 420 430.etc Size:5x5 - 60 x 60 Type: cold drawn
Stainless steel flat bar	Grade:201 304 316L 310S 2205 2507 321 904L 410 420 430.etc Size:103 - 20050mm Type: hot rolled
