ASTM A276 Grade 316L 310S Stainless Angle Bar

ASTM A276 Grade 316L 310S Stainless Angle Bar
ASTM A276 Grade 316L 310S Stainless Angle Bar ASTM A276 Grade 316L 310S Stainless Angle Bar ASTM A276 Grade 316L 310S Stainless Angle Bar ASTM A276 Grade 316L 310S Stainless Angle Bar

Large Image :  ASTM A276 Grade 316L 310S Stainless Angle Bar

Product Details:
Place of Origin: CHINA
Brand Name: GMS
Certification: ISO 9001
Model Number: 201 304 316L 310S
Payment & Shipping Terms:
Minimum Order Quantity: 100 kgs
Price: 1500 USD/Ton
Packaging Details: packing for export
Delivery Time: 5 - 8 days
Payment Terms: T/T, Western Union
Supply Ability: 300 Ton/Month

ASTM A276 Grade 316L 310S Stainless Angle Bar

Description
Products: Stainless Steel Angle Bar Grade: 201 304 316L 310S
Type: Angle Bar Length: 6m
Other Material: Channel Bar, Flat Bar,round Bar.etc Company Type: Factory
Deliver Time: Within 10 Days Service: Cutting
High Light:

310S Stainless Angle Bar

,

316L Stainless Angle Bar

,

ASTM A276 Stainless Angle Bar

ASTM A276 Grade 201 304 316L 310S Stainless Steel Angles / Equal Stainless Steel Angle Bar



Commodity stainless steel angle bar
Size 20mmx20mmx3mm~150mmx150mmx12mm
Length 6m, or as customized
Surface hot rolled
Application Construction field, shipbuilding industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchange, machinery hardware fields
Delivery Time 5 - 8 days, according to quantity
Price Terms FOB/ CFR/ CIF
Package Export standard package, or as per customers' requirement
Other Products stainless steel channel bar,stainless steel round bar, stainless steel flat bar, stainless steel hexagon bar



Element (Wt.%)

  C Mn P S Si Cr Ni N Mo Ti
201 0.15max 5.50-7.50 0.06max 0.030max 1.00max 16.00-18.00 3.50-5.50 0.25max - -
304 0.08max 2.00max 0.045max 0.030max 1.00max 17.50-19.50 8.00-10.50 0.10max - -
316L 0.03max 2.00max 0.045max 0.030max 1.00max 16.00-18.00 10.00-14.00 - 2.00-3.00 -


Mechanical Property

Material Item Tensile Strength (MPa) Yield Strength (MPa) Extension Hardness (HV) Density
201 ≥520 ≥275 ≥40% <253 7.93g/cm³
304 ≥520 ≥205 ≥40% ≤200 7.93g/cm³
316L ≥480 ≥177 ≥40% ≤200 7.98g/cm³



Our Products Detail informations



Stainless steel angle bar

Grade:201 304 316L 310S.etc

Size:30*30*3mm-150*150*10mm x 6m length

Type: equal angle

Stainless steel channel bar

Grade:201 304 316L 310S.etc

Size:4# - 20#

Type: U channel

Stainless steel round bar

Grade:201 304 316L 310S 321 2205 2507 904L.etc

Size:4 - 350mm

Type:  black bar, bright bar

Stainless steel hexagon bar

Grade:201 304 316L 410 420 430.etc

Size:5x5 - 60 x 60

Type: cold drawn

Stainless steel flat bar

Grade:201 304 316L 310S 2205 2507 321 904L 410 420 430.etc

Size:10*3 - 200*50mm

Type: hot rolled



ASTM A276 Grade 316L 310S Stainless Angle Bar 0ASTM A276 Grade 316L 310S Stainless Angle Bar 1ASTM A276 Grade 316L 310S Stainless Angle Bar 2
