Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar

Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar
Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar

Large Image :  Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar

Product Details:
Place of Origin: CHINA
Brand Name: GMS
Certification: ISO 9001
Model Number: 201 304 316L 310S 2205
Payment & Shipping Terms:
Minimum Order Quantity: 500 KGS
Price: 2400 USD/Ton
Packaging Details: wooden frame packing
Delivery Time: 5 - 7 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 50 ton/month

Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar

Description
Products: Stainless Steel Channels Type: U Channel
Size: Width 40-200mm Grade: 201 304 316L 310S 2205.etc
Length: 6m/pcs Service: Cutting
Other Products: Angles. Flat Bar, Round Bar Brand: TSINGSHAN
High Light:

A276 Stainless Steel Channel Bar

,

2205 Stainless Steel Channel Bar

,

310s Stainless Steel Channel Bar

Grade 201 304 316L 310S 2205 Stainless Steel Channels ASTM A276 Stainless Steel Channel Bar



Product Name stainless steel channel
Material stainless steel
Size 50*37*4.5mm -  200*100*10mm
Standard ASTM A276
Grade 201 304 316L 310S 321 2205.etc
Length 6m/pcs
Service cutting
Other products stainless steel anglebar,flat bar,round bar,hexagon bar.etc
Certification: ISO9001, SGS
Packaging PVC waterproof + super strong wooden ocean packaging



Stainless Steel Channel Features & Dimensions

Stainless steel channel offers a wide variety of features and come in a variety of dimensions at Stainless Shapes. Stainless steel channel is shaped using a vertical web with top and bottom flanges at a 90-degree angle to the web and inside radius corners to increase the channel’s strength. Channel can be hot-rolled, extruded, or laser-fused. The following benefits and features make stainless steel channel a great choice for a wide range of industries and applications.

  • Corrosion resistance makes channel an ideal product for chemical, petrochemical, and waste treatment applications
  • Low cost
  • High-temperature resistance
  • Surface finish is ideal for food, medical and pharmaceutical manufacturing applications
  • Easily machinable
  • Weld to exact tolerances



Stainless steel channel dimensions that need consideration are the same dimensions that apply to each of our products. There is height, width, thickness, and length; these all need to fit certain measurements. The height and width are key factors in deciding what kind of channel you need for your application.

Hot rolled stainless steel channel meets the following standards:

  • ASTM A276
  • ASTM A484
  • ASTM A479
  • ASME SA479

Laser fused stainless steel channel is produced to:

  • ASTM A1069/A1069M/11

Dimensional tolerances, and grades according to:

  • ASTM A276
  • ASTM A484
  • ASTM A479/A479

The Two Types of Stainless Channel

Depending on your application and industry, there are two kinds of channel to choose from, U-Channel and C-Channel. Though there are no specific terms, generally the parts of stainless-steel channel are called ‘body’ and ‘legs’. A long body with short legs is a ‘c’ channel, while a short body with long legs is called a ‘u’ channel.

C-Channel: C-channel tends to have shorter legs and thinner bodies overall. This way it can resemble the ‘c’ shape that it is named after. C channel steel is available in:
• 304L
• 316L
Stainless C channel can withstand corrosive environments and is best used around chemicals, acids, and salt water. We offer laser fused non-tapered or hot rolled C channels, tapered.

U-Channel: The U channel is like a square. The best way to produce it is to make all of the portions symmetrical. The U-channel is extremely durable and very reliable. Material available in:
• 304L
• 316L
Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar 0Grade 201 304 316L 310S 2205 ASTM A276 Stainless Steel Channel Bar 1
