Product Details:
|
| Certification: | ISO,BV,SGS | Type: | Round |
|---|---|---|---|
| Application: | Decoration,Industry,Mechineal,shipbuilding | Standard: | DIN,ASTM |
| Grade: | Monel404 | Shape: | Round |
| Dimensions: | 5.5mm-500mm | Surface: | Bright,Polished |
| Technique: | Cold Drawn&hot Rolled | Packing: | Standard Seaworthy Package |
| High Light: | monel 404 bright round bar,shipbuilding bright round bar,5.5mm bright round bar |
||
Monel 404 alloy is used primarily in specialized electrical and electronic applications.The composition of Monel 404 is carefully adjusted to provide a very low Curie temperature, low permeability, and good brazing characteristics.
Monel 404 can be welded using common welding techniques and forged but cannot be hot worked. Cold working may be done using standard tooling and soft die materials for better finish. It is covered by standards UNS N04404 and ASTM F96. This alloy is used in the following applications: capsules for transistors and ceramic to metal sealings.
Chemical composition:
| Grade | Chemical Component % | |||||||
| C | Si | Mn | S | Ni+Co | Fe | Cu | Al | |
| Monel 404 | Max 0.15 | Max 0.10 | Max 0.10 | Max 0.024 | 52.0-57.0 | Max 0.50 | Balance | Max 0.05 |
Application:
1. capsules for transistors
2. ceramic-to-metal sealing
Available products for Monel 404:
Welded pipe/tube
Seamless pipe/tube
Pipe fittings
Flanges
Bar/Profiles
Sheet/ Plate/Coil/Strip
Wire/Wire rope
Forgings
Welding Rod
Fastener
