Product Details:
|
| Certification: | ISO,BV,SGS | Type: | Round,Alloy Steel Bar |
|---|---|---|---|
| Application: | Construction,decoration,Industry,Mechineal | Standard: | DIN,ASTM,AISI |
| Grade: | Nitronic 60 | Shape: | Round |
| Dimensions: | 5.5mm-500mm | Surface: | Bright,Polished,black |
| Technique: | Cold Drawn&hot Rolled | Length: | Customers' Requirements |
| Packing: | Standard Seaworthy Package | Price Term: | CIF CFR FOB Ex-Work |
| High Light: | Nitronic 60 Round Bright Bar,Alloy 218 Round Bright Bar,UNS S21800 Round Bright Bar |
||
| Standards | Designation |
|---|---|
| ASTM | A 276 |
| Length | Diameter |
|---|---|
| 1-6m | 6mm-500mm |
| Type | Certification |
|---|---|
| NITRONIC 60 Round Bar | ISO 9001:2008 |
Below you will find a brief overview of a number of stainless steel bar specifications. If you do not see a specification listed, please contact us.
| BS | JIS | IS | DIN | ASTM | |
|---|---|---|---|---|---|
| Semi Free Cutting Steel | 15AM/8M | SMn433H,SUM 41 |
13S25/ 40C10S 18/40Mn15S12 |
— | 1137,1140 |
| Free Cutting Steel | EN-1A EN-1A L |
SUM-23 SUM-24 L |
11C10S25 —— |
9SMn30 11SMnPb30 |
1212/ 1213 12L15 |
Stainless Steel Bar Specifications |
|||
|---|---|---|---|
ASTM A276 |
This specification encompasses cold-finished or hot-finished bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes, such as angles, tees, and channels in the more commonly used types of stainless steels. | ||
ASTM A479 |
This specification includes cold and hot finished stainless steel bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes such as angles, tees, and channels. | ||
ASTM A484 |
This specification includes wrought stainless steel bars, shapes, forgings, and billets or other semi-finished materials, except wire, for forging. The materials are available in four types of conditions. | ||
ASTM A582 |
This specification includes cold or hot finished bars, which are suitable for machining processes. This specification includes rounds, squares, and hexagons, from common types of stainless free-machining steels. | ||
ASTM B473 |
This specification includes nickel alloy bar & wire, which can be produced in a solution-annealed condition, stabilized-annealed condition, or annealed condition. | ||
| Ni | Cr | Mn | Si | C | N | S | P | Fe | |
|---|---|---|---|---|---|---|---|---|---|
|
MIN
|
8.0
|
16.0
|
7.0
|
3.5
|
-
|
0.08
|
-
|
-
|
-
|
|
MAX
|
9.0
|
18.0
|
9.0
|
4.5
|
0.10
|
0.18
|
0.03
|
0.06
|
Balance
|
| Temperature, °F | 70 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 |
| Coefficient of Thermal Expansion, in/in°F x 10-6 | - | 8.8 | 9.2 | 9.6 | 9.8 | 10.0 | 10.3 | 10.5 | 10.7 | 11.0 |
| Modulus of Elasticity, psi X 106 STA |
- | 26.2 | - | - | - | - | - | - | - | - |
* 70°F to indicated temperature.
| Ultimate Tensile Strength, ksi | 95 |
| 0.2% Yield Strength, ksi | 50 |
| Elongation, % | 35 |
| Reduction of Area, % | 55 |
| Hardness MAX, Brinell | 241 |
Typical Tensile Properties Annealed Bar ¾ – 1"
| Temperature, °F | 68 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 |
| Ultimate Tensile Strength, ksi | 106.5 | 98.2 | 84.4 | 80.5 | 78.3 | 75.4 | 66.6 | 49.8 | 30.2 |
| 0.2% Yield Strength, ksi | 56.5 | 44.4 | 32.8 | 29.7 | 29.0 | 28.0 | 28.1 | 25.3 | 16.4 |
| Elongation, 2% | 61.7 | 63.3 | 64.0 | 59.6 | 65.5 | 52.2 | 48.2 | 47.1 | 72.8 |
