ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible

ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible
ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible

Large Image :  ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: 304
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 1.85 USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible

Description
Steel Grade: 300 Series Type: Welded
Welding Line Type: ERW Standard: ASTM,AISI,DIN
Application: Construction,Decoration,Industry Shape: Round.square.Rectangle
Surface: Annealing Product Name: Stainless Steel Pipe
Thickness: 0.5-25.4mm Length: 6 Meters Or Customized
Outer Diameter: 6mm-630mm Or Customized Technique: Seamless/Welded
Finish: Bright,Brush Polish Price Term: CIF,FOB,CFR,EX-WORK
Trade Terms: FOB CIF CFR CNF EXWORK
High Light:

ASTM 304L Stainless Steel Welded Tube

,

ASTM 304 Stainless Steel Welded Tube

DESCRIPTION

The 304 / 304L grade of austenitic chromium-nickel stainless steel tubes and pipes are the most versatile and widely used steel piping products. Type 304 / 304L stainless steel is a very low carbon steel that exhibits excellent corrosion resistance. Also, it offers superior resistance to intergranular corrosion following welding or stress relieving. Besides, the 304 and 304L type grades exhibit good machinability and excellent weld-ability characteristics with or without filler metals.

304 / 304L STAINLESS STEEL TUBE/PIPE PROPERTIES

Below are the properties of 304 / 304L stainless steel pipes offered by Arch City Steel & Alloy, Inc.:

  • Tough metallic properties
  • High corrosion protection
  • High temperature resistance
  • Ability to be sterilized
  • High workability and machinability
  • Easily welded by all commercial processes
  • Resultant weld has good toughness and ductility
  • High annealing range, between 1850° and 2050°F
  • Non-magnetic in the annealed condition
  • Not hardened by heat treatment
  • Hardness and tensile strength can be increased by cold working
  • Cold working may cause slight magnetism
  • Good wall tolerance and straightness tolerance
  • Cost-effective choice for most applications



Applications of 304 / 304L Stainless Steel Pipes/Tubes



304 Stainless Steel Pipe is most suited for applications where superior strength and excellent corrosion resistance is required. 304 / 304L stainless steel seamless pipes are widely accepted in food processing, water treatment, petrochemical, diary, and chemical industries for moving fluids and gases. Welded 304 / 304L stainless steel tube/pipe is ideally used for posts, and poles as well as handrails, in exterior and marine applications. 304 / 304L pipes find extensive use in applications requiring welding, machining, grinding, forming, and polishing.

Because of their durable mill finish and interior welded seam, these pipes are widely used for projects that are exposed to chemical, acidic elements, fresh water, and salt water environments.



COMPOSITION



Typical Chemical Composition % (max values, unless noted)
Weight % Carbon (C) Manganese (Mn) Phosphorus (P) Sulfur (S) Silicon (Si) Chromium (Cr) Nickel (Ni)
304 .08 2.00 .045 .030 1.00 18.0-20.0 8.0-11.0
304L .035 2.00 .045 .030 1.00 18.0-20.0 8.0-13.0



MECHANICAL PROPERTIES



Typical Room Temperature Mechanical Properties
Type UTS KSI (MPA) 0.2% YS KSI (MPA) Elongation% in 2ʺ(50.8 mm) HardnessRockwell
304 90 (621) 42 (290) 55 B82
304L 85 (586) 35 (241) 55 B80





ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible 0ASTM 304 / 304L Stainless Steel Welded Tube With Bright Mirror Polished Flexible 1
