SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width

SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width
SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width

Large Image :  SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: 316L
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 3.65USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width

Description
Material: Stainless Steel Shape: Flat Plate
Thickness: 1.5-30 Mm Or Customized Width: 10mm-2000mm
Length: 2000-12000mm Finished: 2B BA NO.1
High Light:

2000mm Width Stainless Steel Plates

,

ASTM A240 Steel Plate

,

ASTM A666 Stainless Steel Plates

SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width

In ASTM A240, type 316 and 316L is a chromium nickel austenitic steel, Element molybdenum addition can enhances corrosion resistance of stainless steel, which is the main factor that 316/316l is more corrosion resistant than 304/304l. When 316L steel of low carbon content is only a little higher than 316 steel on strength level. So sometimes grade 316l is almost the same as 316 grade. Another difference, 316l can be used for weld treatment as it contains lower carbon.

316/316L steel has outstanding corrosion resistant properties, whether it is atmospheric or oxidizing environment, even for marine atmosphere, it shows excellent corrosion resistance in welded state. Normally 316/316l steel shows no magnetic in annealed condition, cold drawn or cold rolling process may make it with little magnetic, and it can be fixed with further processing.

Applications of ASTM A240 316/316L

316/316L plate is used to manufacture products for applications that are exposed to salt water, acids such as sulfuric acid and chloride, petrochemicals and chemicals and high-heat such as engines and motors.Products include tanks, supports and frames, enclosures and housings, engine, motor and machinery components and parts.

Chemical Composition of 316/316L Steel Plate

Chemical Composition of 316/316L steel
Element 316 316L
Carbon 0.08 0.030 max
Chromium 16.0-18.0 16.0-18.0
Nickel 10.0-14.0 10.0-14.0
Molybdenum 2.00-3.00 2.00-3.00
Manganese 2.00 2.00
Silicon 0.75 0.75
Nitrogen 0.10 0.10
Phosphorus 0.045 0.045
Sulfur 0.030 0.030

Mechanical Properties of 316/316L Steel Plate

Mechanical Property of 316/316l 316 316L
Yield Strength, min. (ksi) 30 25
Tensile Strength, min. (ksi) 75 70
Elongation, min. (%) 40 40
Hardness, max. (Rb) 95 95

Stainless Steel Standards of 316/316L steel

Steel Standards of 316/316L
316 316L
ASTM A240 ASTM A240
ASTM A666 ASTM A666
ASME SA240 ASME SA240
AMS 5524 AMS 5507

SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width 0SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width 1SS 316L PLATE ASTM A240 316L Stainless Steel Plate NO.1 Finished 2000mm Width 2
