Product Details:
|
| Width: | 600-3000mm | Length: | 1000-12000mm |
|---|---|---|---|
| Thickness: | 3-100mm | Type: | Plate |
| Use: | Ship Building | Classification Society: | BV GL DNV CCS |
| High Light: | shipping plate,marine steel plate |
||
The steel for shipbuilding and oil platform---EH40, is the high tensile strength steel.
It is the Hull structural steel,with it's good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.This kind of steel can be used in the manufacture of the ocean ship's hull structure whose weight is above 10000 tons.
EH40 shipbuilding steel plate specification:
Thickness: 4mm to 260mm, Width: 1200mm to 4000mm, Length: 3000mm to 18000mm.
EH40 shipbuilding steel Mechanical Property Chemical Composition %
Grade |
C max | Si max | Mn | P max | S max | Als min | Ti max | Cu max | Cr max |
Ni max |
Mo max |
Nb | V |
| EH40 | 0.18 | 0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 | 0.02-0.05 | 0.05-0.10 |
Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.40% (thickness ≤ 50mm). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
EH40 shipbuilding steel Mechanical Property Mechanical Property
Grade |
Rm (MPa) |
Re(MPa) min | A% min | Akv/J min | ||||||
| EH40 | 510-660 | 390 | 20 | E.T °C | Thickness (mm) | |||||
| -20 | ≤ 50 | >50-70 | >70-100 | |||||||
| L | C | L | C | L | C | |||||
| 41 | 27 | - | ||||||||
Note: In the list , Rm: tensile strength,Re: Yield strength,A%: elongation, E.T: experimental temperature,L: lengthways, C: crosswise.
EH40 shipbuilding steel Condition Of Delivery
Grade |
Fine grains elements | category | The thickness of steel | |||||
| ≤ 12 | >12.5-20 | >20-25 | >25-35 | >35-50 | >50-100 | |||
| EH40 | any | Plate/ sheet |
N,TM,Q&T | - | ||||
| Profile steel | N(25),TM(25),Q&T(25) | |||||||
Note: 1. delivery condition: A =Any ; N=Normalized ; CR=Control Rolled ; TM=TMPC, Temperature - deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society .
2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.
If you want to know more information about EH40 Shipbuilding steel plate, please contact us and let us know your required specification, the best price will be quoted in shortest time.
