Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish

Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish
Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish

Large Image :  Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish

Product Details:
Place of Origin: China
Brand Name: MITTEL
Certification: SGS ISO MTC
Model Number: 316L
Payment & Shipping Terms:
Minimum Order Quantity: 50KGS
Price: 3.48 USD/KG
Packaging Details: Wooden Box
Delivery Time: 14 Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

Wide 9.5- 420mm Stainless Steel 316 Strips Application Heat Exchanger BA 2B Finish

Description
Length: Customer's Request,in Coil Grade: 300 Series
Application: Construction Type: Cold Rolled Coil
Standard: ASTM,AISI,JIS,DIN Width: 1000-2000mm
Surface: BA,2B Edge: Mill Edge Slit Edge
Price Term: CIF CFR FOB EX-WORK Coil Weight: 1MT - 10MT
High Light:

stainless steel coil stock

,

cold rolled stainless steel coil



1. Products Details

Commodity  316l Stainless Steel Strip
Grade 301,302,304,304L,316,316L,310S,309S,321,301,310
Brand TISCO ,BAOSTEEL,POSCO,JISCO,LISCO
Certification SGS,BV,IQI,TUV,ISO,etc
Thickness 0.3mm-25mm
Width 1000,1219,1250,1500mm, or as your requirements
Length 2000,2438,2500,3000,6000mm, or as your requirements
Surface No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Standard ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc
Delivery 5-7 days after confirming the order
MOQ 1 Ton



2. Chemical Properties:

  C Mn Si P S Cr Mo Ni N
316
(S31600)
0.08
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max
316L
(S31603)
0.03
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max

Mechanical Properties:

Grade Tensile Strength
ksi (min)
Yield Strength
0.2% ksi (min)
Elongation % Hardness (Brinell) MAX Hardness
(Rockwell B) MAX
316
(S31600)
75 30 40 217 95
316L
(S31603)
70 25 40 217 95



316 standards

CHINA:06Cr17Ni12Mo2
ASTM/ASME: UNS S31600 316L
AFNOR: Z 6 CND 17-11
DIN: 1.4401


3. Feather and Applications

1, Features: by adding Mo, so its corrosion resistance, resistance to atmospheric corrosion resistance and high temperature strength particularly well, and can be used in critical conditions. Excellent work hardening (non-magnetic); High temperature strength outstanding; Solid solution state non-magnetic; Cold rolled product outward appearance luster, beautiful; Relative to 304 l stainless steel, the price is higher.
2. Use: water with equipment, chemical, dyestuff, papermaking, oxalic acid, fertilizer and other production equipment; Photography, food industry, coastal facilities, rope, CD rod, bolts and nuts
