Product Details:
|
| Certification: | ISO,BV,SGS | Type: | Round |
|---|---|---|---|
| Application: | Construction,decoration,Industry,Mechineal | Standard: | DIN |
| Grade: | Monel400 | Shape: | Round |
| Dimensions: | 5.5mm-500mm | Surface: | Bright,Polished |
| Technique: | Cold Drawn&hot Rolled | Packing: | Standard Seaworthy Package |
| Price Term: | CIF CFR FOB Ex-Work | ||
| High Light: | ss round bars,stainless steel round rod |
||
Nickel Alloy Monel 400 UNS N04400 Monel 400 and Monel K500 bar rod round bar in stock
1. Monel 400 and Monel K-500 bar rod round bar Specifications
| Specifications | : | ASTM B164 / ASTM SB164 ASTM B865 / ASTM SB865 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 5 mm To 500 mm |
| Diameter | : | 0.1 mm to 100 mm |
| Length | : | 100 mm To 3000 mm Long & Above |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
2. Types of Monel 400 and Monel 400 and Monel K500 Bars / Rods
| Monel 400 and Monel K500 Bright Bar | Monel 400 and Monel® K500 Bright Bar K500 Monel Bright Bar Monel Alloy K500 Bright Bar UNS N05500 Monel Bright Bar WERKSTOFF NR. 2.4375 Bright Bar ASTM B865 K500 Monel Bright Bar |
| Monel 400 and Monel K500 Hex Bar | Monel 400 and Monel® K500 Hex Bar K500 Monel Hexagonal Bar K500 Monel Alloy Hex Bar UNS N05500 Monel Hexagonal Bar ASTM B865 K500 Monel Hex Bar |
| Monel 400 and Monel K500 Square Bar | Monel 400 and Monel® K500 Square Bar K500 Monel Square Bars K500 Monel Alloy Square Bar UNS N05500 Monel Square Bar WERKSTOFF NR. 2.4375 Square Bar ASTM B865 K500 Monel Square Bars |
| Monel 400 and Monel K500 Rectangular Bar | Monel 400 and Monel® K500 Rectangular Bar K500 Monel Rectangular Bars K500 Monel Alloy Rectangular Bar UNS N05500 Monel Rectangular Bars WERKSTOFF NR. 2.4375 Rectangular Bar ASTM B865 K500 Monel Rectangular Bar |
| Monel 400 and Monel K500 Flat Bars | Alloy K500 Flat Bar K500 Monel Alloy Flat Bars K500 Monel Flat Bars UNS N05500 Monel Flat Bars WERKSTOFF NR. 2.4375 Flat Bars ASTM B865 K500 Monel Flat Bars |
| Monel 400 and Monel K500 Polished Bar | Monel 400 and Monel® K500 Polished Bar K500 Monel Polished Bars K500 Monel Alloy Polished Bar UNS N05500 Monel Polished Bars WERKSTOFF NR. 2.4375 Polished Bar ASTM B865 K500 Monel Polished Bar |
| Monel 400 and Monel K500 Threaded Bar | Alloy K500 Threaded Bar K500 Monel® Threaded Bars K500 Monel Alloy Threaded Bar UNS N05500 Monel Threaded Bar WERKSTOFF NR. 2.4375 Threaded Bar ASTM B865 K500 Monel Threaded Bar |
3. More information about Monel 400 and Monel K500 bar rod round bar
400 Monel Alloy Round Bar Chemical Composition
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 28.00 – 34.00 | 2.50 max | 63.00 min | 0.024 max |
Monel Alloy 400 Rods Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40% |
Equivalent Grades for 400 Monel Round Bar
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | BS | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | МНЖМц 28-2,5-1,5 | NA 13 | NU-30M | NiCu30Fe |
K500 Monel Alloy Round Bar Chemical Composition
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min | 0.010 max |
Monel Alloy K500 Rods Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15000 , MPa – 790 | 20% |
Equivalent Grades for K500 Monel Round Bar
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | BS | AFNOR | EN |
| Monel K500 | 2.4375 | N05500 |
4. Monel 400 and Monel K500 Round Bar Application Industries
Off-Shore Oil Drilling Companies
Power Generation
Petrochemicals
Gas Processing
Specialty Chemicals
Pharmaceuticals
Pharmaceutical Equipment
Chemical Equipment
Sea Water Equipment
Heat Exchangers
Condensers
Pulp and Paper Industry
5. Monel 400 and Monel K500 Rods Test Certificates
We provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.
• EN 10204/3.1B,
• Raw Materials Certificate
• 100% Radiography Test Report
• Third Party Inspection Report, etc
ASTM, ASME and API Monel 400 and Monel K500 Bars Value Added Services
Material Testing:
We ensure that all our materials go through strict quality tests before dispatching them to our clients.
• Mechanical Testing Such as Tensile of Area
• Hardness Test
• Chemical Analysis – Spectro Analysis
• Positive Material Identification – PMI Testing
• Flattening Test
• Micro and MacroTest
• Pitting Resistance Test
• Flaring Test
• Intergranular Corrosion (IGC) Test
Documentation
• Commercial Invoice which includes HS Code
• Packing List including net weight and gross weight, number of boxes, Marks and Numbers
• Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
• Fumigation Certificates
• Raw Material Test Reports
• Material Traceability Records
• Quality Assurance Plan (QAP)
• Heat Treatment Charts
• Test Certificates certifying NACE MR0103, NACE MR0175
• Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
• Guarantee Letter
• NABL approved Laboratory Test Reports
• Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
• Form A for the purposes of the Generalized System of Preferences (GSP)
