Product Details:
|
Grade: | Nickel Base Alloy | Application: | Industry,construction,deep-drawn |
---|---|---|---|
Type: | Nickel Plate | Elongation (≥ %): | 40% |
Resistance (μω.m): | Stable | Ni (min): | Balance |
Ultimate Strength (≥ Mpa): | Standard | Surface: | Polished,Black Or Bright |
Shape: | Bar/rod/wire/strip/plate/sheet/pipe/tube/disc/forging/ring/flange | Standard: | ASTM,DIN,EN,AISI |
Material: | Hastelloy C22 | Size: | According To Client's Requirements |
Thickness: | 1mm~30mm | Package: | Wooden Boxes Package |
High Light: | hastelloy c276 plate,hastelloy sheet |
Standard specifications for ASTM B626 Hastelloy C22 Plate. If any specification is not mentioned here, you can contact us. We also manufacture and export any custom specification as per clients requirement.
Specifications | ASTM B626, ASME SB626 |
Dimensions | ASTM, ASME and API |
Size | Thickness 0.5-100mm |
Specialized in | Large Diameter Size |
Range | Width 1000-2500mm |
Type | plate |
Form | plate |
Length | Single Random, Double Random & Cut Length. |
End | Plain End, Beveled End, Threaded |
Grade | ASTM B626 Hastelloy C22 | |
---|---|---|
min | max | |
C | – | 0.010 |
Mn | – | 0.50 |
Si | – | 0.08 |
P | – | 0.02 |
S | – | 0.02 |
Mo | 12.5 | 14.5 |
Ni | Balance | Balance |
Cr | 20.0 | 22.5 |
Fe | 2.0 | 6.0 |
Co | – | 2.5 |
V | – | 0.35 |
W | 2.5 | 3.5 |
Grade | ASTM B626 Hastelloy C22 | |
---|---|---|
Tensile Strength (MPa) min | Psi – 100000 , MPa – 690 | |
Yield Strength 0.2% Proof (MPa) min | Psi – 45000 , MPa – 310 | |
Elongation (% in 50mm) min | 45% |
Grade | ASTM B626 Hastelloy C22 | |
---|---|---|
Density | 8.69 g/cm3 | |
Melting Point | 1399 °C (2550 °F) |
Grade | ASTM B626 Hastelloy C22 | |
UNS No | N06022 | |
Old British | BS | – |
En | NiCr21Mo14W | |
Euronorm | No | 2.4602 |
Name | – | |
AFNOR | – | |
Japanese JIS | NW 6022 | |
GOST | – |
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for ASTM B626 Hastelloy C22 plate
