Product Details:
|
| Grade: | Nickel Base Alloy | Application: | Industry,construction,used In Chemical |
|---|---|---|---|
| Type: | Nickel Plate | Ni (min): | Balance |
| Ultimate Strength (≥ Mpa): | DIN,Standard | Surface: | Black Or Bright |
| Standard: | ASTM | Material: | Hastelloy C22 |
| Thickness: | 1mm~30mm | ||
| High Light: | hastelloy c276 plate,hastelloy sheet |
||
|
Chemical Analysis |
|
| C | .015 max |
| MN | .50 max |
| P | .02 max |
| S | .02 max |
| Si | .08 max |
| Cr | 20.0- 22.0 |
| Ni | rem |
| Mo | 12.5- 14.5 |
| Co | 2.5 max |
| Ti | 0.6- 1.2 |
| Al | 0.2 max |
| Fe | 2.0- 6.0 |
| W | 2.5- 3.5 |
| V | .35 max |
Magellan Metals offers Hastelloy C22® in a variety of forms, including:
Hastelloy C22® sheet is available in thicknesses ranging from .038 to .141". Hastelloy C22® strip in coil from is available in lighter gauges up 12" wide. Hastelloy C22® plate is available up 2" thick.
Hastelloy C22® bar is available in wrought bar up to 11" diameter and larger sizes and shapes may be forged to order.
Hastelloy C22® seamless pipe is available up to 2" NB. Larger sizes are available in welded construction (100% X-ray) and can also be fabricated to order. Hastelloy C22® tubing is available up 2" OD in welded & 1/2" OD isn seamless construction. Hastelloy C22® redrawn tubes and tubing with tight tolerances can be supplied in almost any size no matter how small the size or quantity.
Butt-weld and forged fittings are available or can be manufactured with short lead times.
|
|
