Product Details:
|
| Grade: | Stainless Steel | Shape: | U Channel,C Channel |
|---|---|---|---|
| Standard: | ASTM | Application: | Construction |
| Dimensions: | 50*37*4.5-400*104*14.5 | Material: | Stainless Steel |
| Product Name: | Stainless Strut Steel U Channel | Technique: | Hot Rolled Steel Channel,Cold Rolled |
| Type: | U Channel Steel,Stainless Steel Profile-U Channel | Length: | 5.8M-12M |
| Thickness: | 4.5-14.5mm | Name: | Hot Rolling Grade 304 /316 U Shape Stainless Steel Channel |
| Surface: | Pickled Polish Bright | Color: | As Customer's Requirement |
| Loading Port: | Shanghai | ||
| High Light: | SS u channel,stainless steel c channel |
||
316L Stainless Steel Channel Bar AISI 316L U Channel Bar
| ITEM | Stainless Steel Channels |
| Material | Mittel ,BAOSTEEL, JISCO, TISCO, etc. |
| Size | 50*37mm*4.5-400*104*14.5mm or customized |
| Length | 6m,9m,12m or as required |
| Surface | Pickling, hot rolled, annealed |
| Grade |
201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430.410. 440.904Lect. Or Customized |
| Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
| Trade Term | FOB CIF CFR CNF EXWORK |
| Application | Architecture and engineer structure ,industry ,etc |
| Package | Standard export sea-worthy packing or customized |
| Delivery | 7-15 days after deposit |
| Payment | TT/LC |
| Sample | Offer the sample for free charge but do not pay the cost of freight |
| Channel Stainless Steel | |||||
| Size(mm) |
Theoretical weight (kg/m) |
Size(mm) |
Theoretical weight (kg/m) |
||
| 5 | 50*37*4.5 | 5.438 | 22b | 220*79*9 | 28.453 |
| 6.3 | 63*40*4.8 | 6.634 | 25a | 250*78*7 | 27.41 |
| 6.5 | 65*40*4.8 | 6.709 | 25b | 250*80*9 | 31.335 |
| 8 | 80*43*5 | 8.045 | 25c | 250*82*11 | 35.26 |
| 10 | 100*48*5.3 | 10.007 | 28a | 280*82*7.5 | 31.427 |
| 12 | 120*53*5.5 | 12.059 | 28b | 280*84*9.5 | 35.823 |
| 12.6 | 126*53*5.5 | 12.318 | 28c | 280*86*11.5 | 40.219 |
| 14a | 140*58*6 | 14.535 | 30a | 300*85*7.5 | 34.463 |
| 14b | 140*60*8 | 16.733 | 30b | 300*87*9.5 | 39.173 |
| 16a | 160*63*6.5 | 17.24 | 30c | 300*89*11.5 | 43.883 |
| 16b | 160*65*8.5 | 19.752 | 36a | 360*96*9 | 47.814 |
| 18a | 180*68*7 | 20.174 | 36b | 360*98*11 | 53.466 |
| 18b | 180*70*9 | 23 | 36c | 360*100*13 | 59.118 |
| 20a | 200*73*7 | 22.64 | 40a | 400*100*10.5 | 58.928 |
| 20b | 200*75*9 | 25.777 | 40b | 400*102*12.5 | 65.204 |
| 22a | 220*77*7 | 24.999 | 40c | 400*104*14.5 |
71.488 |
Q1. Where is your factory ?
A1: Our company’s processing center is located in Wuxi, Jiangsu, China.
Which is well equipped with kinds of machines, such as laser cutting machine,mirror polishing machine and so on.We can provide a wide range of personalized services according to the customers’ needs.
Q2. What are your company's main products ?
A2: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.
Q3. How do you control quality ?
A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.
Q4. What are the advantages of your company ?
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q5. How many coutries you already exported ?
A5: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Iran, Turkey, Jordan,
India, etc.
Q6. Can you provide sample ?
A6: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7days.
