Product Details:
|
| Material: | Stainless Steel | Metal Type: | Stainless Steel |
|---|---|---|---|
| Thickness: | 1-3mm,1.0mm Or Customized | Surface: | According To Customer Demand,Mirror Or Matt |
| Width: | 1000-3000mm | Length: | 2000-12000mm |
| High Light: | precision ground stainless steel plate,stainless steel sheets and plates |
||
Stainless steel grade 314 has excellent high-temperature resistance characteristics among the chromium-nickel steels series. The silicon content in this material improves oxidation and carburization resistance; however, it can become very brittle when subjected to prolonged temperatures of 649-816°C (1200- 1500°F).
Chemical Composition
| Element | Content (%) |
|---|---|
| Iron, fe | Balance |
| Chromium, Cr | 23-26 |
| Nickel, Ni | 19-22 |
| Manganese, Mn | 2 |
| Silicon, Si | 1.5-3 |
| Carbon, C | 0.25 |
| Sulfur, S | 0.03 |
| Phosphorous, P | 0.045 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 689 MPa | 99900 psi |
| Yield strength | 345 MPa | 50000 psi |
| Modulus of elasticity | 200 GPa | 29000 ksi |
| Elongation at break (in 50 mm) | 40% | 40% |
| Hardness, Rockwell B | 85 | 85 |
Grade 314 steel is widely used in the following applications:
