409 Stainless Steel Exhaust Tubing Type , SUH 409 Stainless Steel Welded Tube

Large Image : 409 Stainless Steel Exhaust Tubing Type , SUH 409 Stainless Steel Welded Tube

Product Details:

Place of Origin:	China
Brand Name:	TISCO BAO STEEL
Certification:	SGS ISO MTC
Model Number:	SUH409L

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	1.95 USD/KG
Packaging Details:	Export Packing
Delivery Time:	14 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

409 Stainless Steel Exhaust Tubing Type , SUH 409 Stainless Steel Welded Tube

Description

OD:	6-127mm	Thickness:	0.5-3mm
Length:	6000mm	Surface:	2B 2D
Grade:	SUH409L	Type:	Wleded
Highlight:	stainless steel pipe astm , stainless steel pipe welding standards

409 Stainless Steel Exhaust Tubing Type SUH 409 Stainless Steel Welded Pipe

Specifications

409l exhaust muffler pipes
1.OD:12-114mm
2.WT:1.0-2.0mm
3.Usage:Automotive Muffler,Shock Absorber
4.High quality,Best price

409l exhaust muffler pipes

1. Features of 409l exhaust muffler pipes :
1) Inside and outside bead scarfing
2) Higher expansion rate
3) Smooth surface roughness
4) Accurate roundness

2. Specifications of 409l exhaust muffler pipes :
1) Standard: GB/T12770-2002, ASTM, JIS ect.
2) Grade: SUH409L
3) Outside Diameter: 12-114mm
4) Wall Thickness: 1.0-2.0mm
5) Length:5.8 meters or according to your request
6) Type: Welded

3. Application of 409l exhaust muffler pipes :
1) Muffler tube of exhaust systems
2) Cylinder tube of shock absorber and steering parts ect

4. Manufacturing process of 409l exhaust muffler pipes :

5. Chemical composition and Mechanical property of 409l exhaust muffler pipes :

Material	Chemical Composition (%)						Mechanical Properties
Material	C max	Si max	Mn max	P max	S max	Cr	T.SN/ mm2	Y.pN/ mm2	E.L%	Hardness HRB
SUH409L	0.03	1.00	1.00	0.04	0.03	10.50-11.75	360	175	25	8

6. Packing of 409l exhaust muffler pipes :

In bundles and wrapped with anti-rust paper.
Or according to your requests.

7. Export markets of 409l exhaust muffler pipes :
Egypt, Iran, Kuwait, Algeria, Saudi Arabia, South Africa, India, Malaysia, Indonesia,

Canada, Brazil, Mexico, Venezuela ect.

8. Main dimensions of 409l exhaust muffler pipes :

Outside Diameter (mm)	Wall Thickness
mm	mm
12	1.0	1.2	1.5
12.7	1.0	1.2	1.5
13	1.0	1.2	1.5
15.9	1.0	1.2	1.5
16	1.0	1.2	1.5
17.3	1.0	1.2	1.5
19.1	1.0	1.2	1.5
20	1.0	1.2	1.5
22	1.0	1.2	1.5
22.2	1.0	1.2	1.5
24.4	1.0	1.2	1.5
25	1.0	1.2	1.5
25.4	1.0	1.2	1.5
28	1.0	1.2	1.5
28.6	1.0	1.2	1.5
29	1.0	1.2	1.5
30	1.0	1.2	1.5
32	1.0	1.2	1.5
35	1.0	1.2	1.5
36	1.0	1.2	1.5
38	1.0	1.2	1.5
38.7	1.0	1.2	1.5
39	1.0	1.2	1.5
40	1.0	1.2	1.5
41	1.0	1.2	1.5
42	1.0	1.2	1.5
42.7	1.0	1.2	1.5
43	1.0	1.2	1.5
45	1.0	1.2	1.5
48	1.0	1.2	1.5
48.6	1.0	1.2	1.5
50	1.0	1.2	1.5
50.8	1.0	1.2	1.5
52	1.0	1.2	1.5
53	1.0	1.2	1.5
54	1.0	1.2	1.5
55	1.0	1.2	1.5
57	1.0	1.2	1.5
57.2	1.0	1.2	1.5
58.5	1.0	1.2	1.5
60	1.0	1.2	1.5
64	1.0	1.2	1.5
65	1.0	1.2	1.5
68.5	1.0	1.2	1.5
70	1.0	1.2	1.5
75.6	1.0	1.2	1.5
76	1.0	1.2	1.5
82	1.0	1.2	1.5
89	1.0	1.2	1.5

If any question or inquiry,please contact us freely.
