Product Details:
|
| Material: | Stainless Steel | Application: | Industry,Auto Parts,Machinery Parts,Machinery Partsdustry |
|---|---|---|---|
| Process: | Precision Die Casting | Dimensions: | Customized Sizes,5-1000mm |
| Grade: | 304 | Hole: | 1-300mm |
| High Light: | stainless steel metal sheet,stainless steel panels |
||
Specifications
| tem | stainless steel sheet(Hot rolled or cold rolled) |
| Standard | ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc |
| Material |
310S,310,309,309S,316,316L,316Ti,317,317L,321,321H,347,347H,304,304L, 302,301,201,202,403,405,409,409L,410,410S,420,430,631,904L,Duplex,etc |
| Surface |
2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror,checkered,embossed,hair line,sand blast, Brush,etching,etc |
| Thickness | 0.3~100mm |
| Width | 1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,etc |
| Length | 2000mm,2440mm,3000mm,5800mm,6000mm,etc |
| Package | Standard export package,suit for all kinds of transport,or as required. |
|
Container Size |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High) |
| Price term | Ex-Work,FOB,CNF,CFR,CIF,etc |
| Payment term | TT,L/C |
| Export to |
Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA,Brazil,Thailand,Korea, Iran,India,Egypt,Oman,Malaysia,Bangladesh,Dubai,Viet Nam,Kuwait,Peru,Mexico,Russia,etc |
| MOQ | 1 Ton |
| Application |
Stainless steel plate applies to construction field, ships building industry, petroleum,chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields.Stainless steel plate can be made according to the customers requirements. |
| Contact |
If you have any question,please feel free to contact me . we are sure your inquiry or requirements will get prompt attention |
Stainless Steel sheet Chemical Composition
| Grade | STS304 | STS 316 | STS430 | STS201 |
| Elong(10%) | Above 40 | 30MIN | Above 22 | 50-60 |
| Hardness | ≤200HV | ≤200HV | Below 200 | HRB100,HV 230 |
| Cr(%) | 18-20 | 16-18 | 16-18 | 16-18 |
| Ni(%) | 8-10 | 10-14 | ≤0.60% | 0.5-1.5 |
| C(%) | ≤0.08 | ≤0.07 | ≤0.12% | ≤0.15 |
Surface Introduction
|
Surface
|
Definition |
Application
|
| No.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe. |
| 2B(No.2B) | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. |
Medical equipment, Food industry, Construction material, Kitchen utensils.
|
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction.
|
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction, Medical equipment.
|
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size | Building Construction. |
| BA(No.6) | Those processed with bright heat treatment after cold rolling. |
Kitchen utensils, Electric equipment, Building construction.
|
| Mirror(No.8) | shinning like a mirror | Building construction decoration |
Application
Stainless steels of various kinds are used in thousands of applications.The following gives a flavour of thefull
range:
Stainless steel plate applies to construction field, ships building industry, petroleum,chemical
industries, war and electricity industries, food processing and medical industry, boiler heat
exchanger, machinery and hardware fields.Stainless steel plate can be made according to
the customers requirements.
Regular Size
| Thickness (mm) | Width (mm) | Length (mm) |
| 0.5 | 1000 | 2000 |
| 0.5 | 1219 | 2438 |
| 0.6 | 1000 | 2000 |
| 0.6 | 1219 | 2438 |
| 0.7 | 1000 | 2000 |
| 0.7 | 1219 | 2438 |
| 0.8 | 1000 | 2000 |
| 0.8 | 1219 | 2438 |
| 1.0 | 1000 | 2000 |
| 1.0 | 1219 | 2438 |
| 1.2 | 1000 | 2000 |
| 1.2 | 1219 | 2438 |
| 1.5 | 1000 | 2000 |
| 1.5 | 1219 | 2438 |
| 2.0 | 1000 | 2000 |
| 2.0 | 1219 | 2438 |
| 2.5 | 1000 | 2000 |
| 2.5 | 1219 | 2438 |
| 3.0 | 1000 | 2000 |
| 3.0 | 1219 | 2438 |
| 3.0 | 1500 | 6000 |
