34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure

34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure
34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure 34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure

Large Image :  34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure

Product Details:
Place of Origin: CHINA
Brand Name: MITTEL
Certification: SGS
Model Number: 34CrMo4
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Price: 850 USD/TON
Packaging Details: EXPORT PACKING
Delivery Time: 7 DAYS
Payment Terms: L/C, T/T
Supply Ability: 500 TONS

34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure

Description
OD: 8-630mm Thickness: 1-60mm
Surface: Black AND Bright Length: 6m
Type: Seamless Condition: Cold Drawn
High Light:

seamless stainless steel tube

,

ss seamless pipes

34CrMo4 Cold Drawn Steel Tube For Cold Rolled Mechanical DIN 2391 Seamless High Pressure Hydraulic

(1) Product Name : Hot Rolled / Hot expansion Seamless Carbon Steel Pipe
(2) Brand : Jiangsu MITTEL

(3) Specification: O.D : 60.3mm-914.4mm W.T : 3.91mm-59.54mm
(4) Standard :

ASTM A106-B ASTM A53-B API 5L-B

API 5L, X42, X52, and 5CT ,J55 ,K55
SAE1020 ,SAE1045
JIS G4051, S20C ,S45C, JIS G3454, JIS 3454 ,STPG42
DIN 17175 ST 45-8, ST 52
(5) Tolerance: OD :+1% / -1% WT: +12.5% / -10%
(6) Technics : hot rolled .or cold rolled
(7) Package: bundles,seaworthy wooden cases,container

(8) Ends:bevel or plain

(9) Coating: Internally bare, externally varnished





Specifications:



Production process of hot rolled tubes :
Hot rolling → heating → piercing → three roller helical rolling, tandem rolling or extrusion → tube knockout → sizing or tube diameter reduction → cooling → semi-finished hot rolled seamless pipe → straightening → water pressure test → labeling → warehousing.

Classifications :
Hot rolled seamless steel tubes can be classified into the common steel pipe, low and medium pressure boiler seamless steel tube, high pressure boiler seamless pipe, stainless steel hot rolled pipe, and more.

Advantages :
Due to our adoption of hot rolling process, the original casting structure of the steel slab for making hot rolled pipe is destroyed. This means that the crystalline grains of steel material are refined, and the defects of the microstructure of steel slab are eliminated, which results in improved mechanical performance and denser microstructure of steel materials along the rolling direction.
Hence, our hot rolled seamless steel pipe features good mechanical property and superior intensity.





Regular Hot Rolled Pipe Sizes:



(Or per customers’ requirements)



OD × WT (mm) OD × WT (mm) OD × WT (mm) OD × WT (mm) OD × WT (mm)
12×1.5 133 ×4~12 406.4×6~25 73×4-4.5-5-6-7-8-9-10-12-15 219×30-40
14×1.5-2.5-3 141.3×4~12 426 ×6~25 76×4-4.5-5-6-7-8-9-10-12-14 245×8-10-14-17-20-22
16×1.5-2.5-4 159 ×4~12 457 ×6~38 83×4.5-5-10/ 12 14 16 18 20 245×25-28-30-34-40
18×2.3-4-5 165 ×4~20 508 ×6~38 89×4.5-8-10/12-14 16 -18 20 273×7-9-12-15-18-20-25
20×2.5-3-5 168.3×4~20 530 ×6~40 95×4.5-6-8/10-12-14-16-20 273×30-35-38-40
24×2.5-3-4-5-6 177.8×4~22 559 ×6~40 102×4.5-5-6-7-8-10-12-14-16-20 299×8-12-16-20-24-28
25×2.5-3-4-5-6 323.8×6~25 610 ×6~40 108×4.5-5-6-7-8-10/12-14-18-20-22 299×30-32-36-38-40
28×3-3.5-4-5-6 340 ×6~25 630 ×6~40 114×4.5-5-6-7-8-10-12-14-18-20 325×8-12-14-18-38
32×3.5-4-5-6-8 355.6×6~25 >630×6~44 121×4.5-5-6-7-8-10-12-14-16-20 325×28-32-34-38
34×4-5-6-8 377 ×6~25 <914×6~60 127×4.5-5-6-7-8-10-12-14-16-20 351×10-16-20-25-40





Applications:



Transportation of oil,gas or fluid,Construction,Electricity,Machine building industy,Chemical industy,Petroleum,Traffic, etc



Competitive Advantage:

Mittel is one of the largest seamless steel pipe manufacturers in China.We’ve passed API 5L,API 5CT, PED, BV, TUV certification and ISO quality system certification.With good quality and competitive price, we believe we could be your reliable supplier.

34CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure 034CrMo4 Cold Drawn Steel Tube Mechanical DIN 2391 Ss Seamless Pipes High Pressure 1
