ASTM AH36 CCS Ship Steel Plate , Mechanical Properties LR Shipbuilding Plate

CCS Grade AH36 shipbuilding steel plate owned higher yield strength and tensile strength.Shipbuilding steel plate CCS Grade AH36 is the Hull structural steel,with it's good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.

Technical Requirements & Additional Services:
♦ High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Cetificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user’s demands

►Mechnical property for CCS Grade AH36 shipbuilding structual steel:


Yield strength (≥Mpa)	Tensile strength (Mpa)	Elongation in ≥,%
355	490-620	200mm	50mm
		19	22

►Chemical composition for CCS Grade AH36 ship steel (Heat Analysis Max%)


Main chemical elements composition of CCS Grade AH36
C	Si	Mn	P	S	Al (acid) min.	Nb
0.18	0.10-0.50	0.90-1.60	0.035	0.035	0.015	0.02-0.05
V	Ti	Cu	Cr	Ni	Mo
0.05-0.10	0.02	0.35	0.20	0.40	0.08

AH36,CCS/AH36|CCS GRADE AH36,CCS AH36 STEEL PLATE

•
•

Gangsteel is specialized in supplying CCS high strength steel plate in CCS Grade AH36. For more information of Grade AH36 steel plate, please check them in following:





CCS/AH36 high Strength Chemical Composition in Tempering and Quenching
Grade	The Element Max (%)
	C	Si	Mn	P	S	Al	N
CCS/AH36	0.18	0.1-0.50	0.90-1.6	0.035	0.035	0.015
	Nb	V	Ti	Cu	Cr	Ni	Mo
	0.02-0.05	0.05-0.10	0.02	0.35	0.2	0.4	0.08

Crack Sensitivity: Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%









CCS/AH36 high strength property in tempering and quenching
Grade		Mechanical Property			Charpy V Impact Test
	Thickness	Yield	Tensile	Elongation	Degree	Energy 1	Energy 2
CCS/AH36	mm	Min Mpa	Mpa	Min %	0	J	J
	t≤50	355	490-620	21%		24	34
	50＜t≤70	355	490-620	21%		27	41
	70＜t≤100	355	490-620	21%		34	50
Note: Energy 1 is transverse impact test, Energy 2 is longitudinal



Boiler steel plates| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate







Equivalent steel grade of CCS/AH36
DNV	GL	LR	BV	ABS	NK	KR	RINA
NV A36	GL-A36	LR/AH36	BV/AH36	ABS/A36	K A36	R A36	RI/A36





If you need more stock steel plates in shipbuilding steel plate, please click warehouse sizes.

Related steel grades: CCS/DH36, CCS/EH36, CCS/FH36, CCS/AH32



CCS Steel Plate Grade
General Strength	CCS/A	CCS/B	CCS/D	CCS/E
High Strength	CCS/A32	CCS/D32	CCS/E32	CCS/F32
	CCS/A36	CCS/D36	CCS/E36	CCS/F36
	CCS/A40	CCS/D40	CCS/E40	CCS/F40
Extra Strength	CCS/A420	CCS/D420	CCS/E420	CCS/F420
	CCS/A460	CCS/D460	CCS/E460	CCS/F460
	CCS/A500	CCS/D500	CCS/E500	CCS/F500
	CCS/A550	CCS/D550	CCS/E550	CCS/F550
	CCS/A620	CCS/D620	CCS/E620	CCS/F620
	CCS/A690	CCS/D690	CCS/E690	CCS/F690
