4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet

4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet
4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet 4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet 4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet 4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet

Large Image :  4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet

Product Details:
Place of Origin: China
Brand Name: TISCO
Payment & Shipping Terms:
Minimum Order Quantity: 2 tons
Price: USD 2200-4300 per ton
Packaging Details: In bundles with seaworthy wooden pallets or as per requirement.
Delivery Time: within 7-10 days after received your payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 4000 tons per month

4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet

Description
Certification: CE, ISO, BV, SGS Model Number: 317L
Product Name: 2B Finsh Grade 317L Stainless Steel Sheet Length: 1000mm-6000mm
Width: 1000mm-2000mm Thickness: 10mm-25mm
Standard: ASTM, AISI, JIS, DIN, EN, GB Technique: Cold Rolled Or Hot Rolled
Application: Industrial, Construction Trade Term: EX-work,FOB,CFR,CIF
Surface: NO.1 Finish
High Light:

stainless steel panels

,

stainless steel plate

4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet



317l 10mm thickness stainless steel sheet supplier
  • Delivery 3 or 5 workdays in Stock
  • Material Grade:317l
  • width 1000 1219 1500 1800 2000mm or as your request
  • Thickness:0.2-150mm;
  • Length:2000 2438 2500 3000 6000mm or customized
  • Original :Tisco
  • Surface:NO.1 2B BA 8K BRUSH HL NO.4 ECT.
  • Payment:T/T, L/C, D/P,D/A
1. Specifications about stainless steel sheet
ITEM Stainless Steel Sheet From China Facotry
Brand RONSCO,BAOSTEEL, JISCO, TISCO, etc.
Grade

201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430.630.631

.410.440.904Lect. Or Customized

Certificate SGS,BV,IQI,TUV,ISO,etc
Surface No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Standard GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Package Standard export sea-worthy packing or customized
MOQ 1Ton
Contact Contact Evans( MP/WhatsApp/Viber/Skype: 0086-18651134538)

2. Chemical Composition about stainless steel sheet
Grade C Si Mn P S Ni Cr Mo
201 ≤0.15 ≤0.75 5.5-7.5 ≤0.06 ≤0.03 3.5-5.5 16.0-18.0 -
202 ≤0.15 ≤1.0 7.5-10.0 ≤0.06 ≤0.03 4.-6.0 17.0-19.0 -
301 ≤0.15 ≤1.0 ≤2.0 ≤0.045 ≤0.03 6.0-8.0 16.0-18.0 -
302 ≤0.15 ≤1.0 ≤2.0 ≤0.035 ≤0.03 8.0-10.0 17.0-19.0 -
304 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 8.0-10.5 18.0-20.0 -
304L ≤0.03 ≤1.0 ≤2.0 ≤0.035 ≤0.03 9.0-13.0 18.0-20.0 -
309S ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 12.0-15.0 22.0-24.0 -
310S ≤0.08 ≤1.5 ≤2.0 ≤0.035 ≤0.03 19.0-22.0 24.0-26.0 -
316 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤0.03 10.0-14.0 16.0-18.0 2.0-3.0
316L ≤0.03 ≤1.0 ≤2.0 ≤0.045 ≤0.03 12.0-15.0 16.0-18.0 2.0-3.0
321 ≤0.08 ≤1.0 ≤2.0 ≤0.035 ≤0.03 9.0-13.0 17.0-19.0 -
630 ≤0.07 ≤1.0 ≤1.0 ≤0.035 ≤0.03 3.0-5.0 15.5-17.5 -
631 ≤0.09 ≤1.0 ≤1.0 ≤0.030 ≤0.035 6.50-7.75 16.0-18.0 -
904L ≤2.0 ≤0.045 ≤1.0 ≤0.035 - 23.0-28.0 19.0-23.0 4.0-5.0
2205 ≤0.03 ≤1.0 ≤2.0 ≤0.030 ≤0.02 4.5-6.5 22.0-23.0 3.0-3.5
2507 ≤0.03 ≤0.80 ≤1.2 ≤0.035 ≤0.02 6.0-8.0 24.0-26.0 3.0-5.0
2520 ≤0.08 ≤1.5 ≤2.0 ≤0.045 ≤0.03 0.19-0.22 0.24-0.26 -
410 ≤0.15 ≤1.0 ≤1.0 ≤0.035 ≤0.03 - 11.5-13.5 -
430 ≤0.12 ≤0.75 ≤1.0 ≤0.040 ≤0.03 ≤0.60 16.0-18.0 -

3. Production Flow about stainless steel sheet

Raw materials are sending to hot rolling units for rolling into different sizes:

317l 10mm thickness stainless steel sheet supplier

317l 10mm thickness stainless steel sheet supplier



Stainless steel maintenance:

(1) Regular cleaning and maintenance

(2) Pay attention to prevent the occurrence of the phenomenon of surface scratches

(3) Use soap, weak detergent or warm water to remove surface dust, dirt

(4) In addition to the surface of the binder with alcohol or an organic solvent (ether, benzene)

(5) Use neutral detergent or ammonia solution in addition to surface oil

(6) With 10% nitric acid or abrasive detergent in addition to the surface of the embroider caused by the dirt.



4.Surface--stainless steel sheet



Surface Finish Definition Application
2B Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. Medical equipment, Food industry, Construction material, Kitchen utensils.
BA/8K mirror Those processed with bright heat treatment after cold rolling. Kitchen utensils, Electric equipment, Building construction.
NO.3 Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. Kitchen utensils, Building construction.
NO.4 Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. Kitchen utensils, Building construction, Medical equipment.
Hairline Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. Building Construction.
NO.1 The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. Chemical tank, pipe.
317l 10mm thickness stainless steel sheet supplier



4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet 3



4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet 4



4x8' 2B Finsh Grade 317L 10mm Thickness Stainless Steel Sheet 5
