ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet

ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet
ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet

Large Image :  ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet

Product Details:
Place of Origin: China
Brand Name: TISCO BAO STEEL ZPSS
Certification: SGS ISO
Model Number: 321
Payment & Shipping Terms:
Minimum Order Quantity: 2 Tons
Price: 2350-3245 USD/Ton
Packaging Details: Export Packing
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Tons
Contact Now

ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet

Description
Thickness: 0.5-100mm Width: 1000-2000mm
Length: 1000-12000mm Surface: 2B NO.1
Type: Hot Rolled Cold Rolled
Highlight:

stainless steel plate

,

stainless steel panels

ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet

  • AMS 5510
  • AMS 5645
  • UNS S32100
  • ASTM A 167
  • PWA-LCS
  • GE-S400/1000
  • RR SABRe Edition 2
  • DFARS Compliant

Common Trade Names

  • ATI 321 (™ Allegheny Technologies)

Common Applications of 321 Stainless Steel

  • Aircraft exhaust stacks
  • Manifolds
  • Chemical processing equipment
  • Welded equipment
  • Jet engine parts

Inventory Size Range

  • Sheet : 0.011" - 0.130"
  • Bar : 0.375" - 9.000"
  • Hex Bar : 0.4375" - 1.125"
  • Plate : 0.250"

Please contact us for more details.

The technical data provided is for information only and not for design purposes. It is not warranted or guaranteed.

321 Chemical Composition


Element Maximum Unless Range is Specified
321 347
Carbon 0.08 0.08
Manganese 2.00 2.00
Phosphorus 0.045 0.045
Sulfur 0.030 0.030
Silicon 0.75 0.75
Chromium 17.00-19.00 17.00-19.00
Nickel 9.00-12.00 9.00-13.00
Columbium+Tantalum - 10xC min to 1.00 max
Titanium 5x(C+N) min to 0.70 max -
Nitrogen 0.10 -
Iron Balance Balance



321 Physical Properties

Grade Density Modulus of Elasticity in Tension Melting Range
g/cm3 lb/in3
321 7.92 0.286 28 x 106 psi
193 GPa		 1398-1446°C
2550-2635°F
347 7.96 0.288 28 x 106 psi
193 GPa		 1398-1446°C
2550-2635°F



Mean Coefficient of Linear Thermal Expansion
Temperature Range Coefficients
°C °F cm/cm/°C in/in/°F
20-100 68-212 16.6 x 10-6 9.2 x 10-6
20-600 68-912 18.9 x 10-6 10.5 x 10-6
20-1000 68-1832 20.5 x 10-6 101.4 x 10-6



Thermal Conductivity
Temperature Range W/m·K Btu · in / hr · ft2 · °F
°C °F
20-100 68-212 16.3 112.5
20-500 68-932 21.4 147.7



Specific Heat
Temperature Range J/kg K Btu/lb · °F
°C °F
0-100 32-212 500 0.12

Magnetic Permeability

  • H/m Annealed
  • 1.02 Max

Electrical Resistivity
Temperature Range microhm·cm
°C °F
20 68 72
100 213 78
200 392 86
400 752 100
600 1112 111
800 1472 121
900 1652 126

Mechanical Properties and Yield Strength of 321


Property Type 321 Type 347
Yield Strength, 0.2% Offset
psi
MPa		 30,000
205		 30,000
205
Ultimate Tensile Strength,
psi
MPa		 75,000
515		 75,000
515
Percent Elongation in 2 in. or 51 mm 40.0 40.0
Hardness, Max.,
Brinell (Plate)
RB (Sheet & Strip)		 217
95		 201
92



ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet 0ASTM A240 AISI 321 Stainless Steel Plate X10CrNiTi189 Inox 321 Stainless Steel With Data Sheet 1



FAQ

1.Q: Why choose us?

A: We are an iron and steel enterprise integrating industry and trade, Our company have been in steel business for more than ten years, we are internationally experienced, professional, and we can provide variety of steel products with high quality to our clients.


2.Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.

3.Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.

4.Q: Do you accept the third party inspection?
A: Yes absolutely we accept.

5.Q: How could you guarantee your products?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.

6.Q:About product prices?

A:Prices vary from period to period due to cyclical changes in the price of raw materials.



7.Q: How can I get your quotation as soon as possible?
A: The email and fax will be checked within 24 hours,meanwhile,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement and order information,specification(Steel grade,size,quantity,destination port),we will work out a best price soon.
