Product Details:
|
| Grade: | 301 | Thickess: | 0.05-3mm |
|---|---|---|---|
| Width: | 10-2000mm | Hardness: | Full Hard 1/2H 3/4H |
| High Light: | stainless steel coil stock,cold rolled stainless steel coil |
||
301 Stainless Steel Full Hard UNS S30100 301 Stainless Steel Strip No Magnetic
301-1/2 Hard is an austenitic stainless steel that it has been cold rolled to its 1/2 hard condition. This makes it ideal for applications requiring both formability and tensile strength of 150,000 PSI and yield strength of 110,000 PSI.
Please contact us for more details.
The technical data provided is for information only and not for design purposes. It is not warranted or guaranteed.
| Element | Percent by Weight |
|---|---|
| Carbon | 0.15 maximum |
| Manganese | 2.00 maximum |
| Phosphorus | 0.045 maximum |
| Sulfur | 0.03 maximum |
| Silicon | 1.00 maximum |
| Chromium | 16.00 - 18.00 |
| Nickel | 6.00 - 8.00 |
| Nitrogen | 0.10 maximum |
* In the cold worked condition, the modulus is lowered.
| Temperature Range | Coefficients | ||
|---|---|---|---|
| °C | °F | cm/cm°C | in/in/°F |
| 20-100 | 68-212 | 16.6 x 10-6 | 9.2 x 10-6 |
| 20-300 | 68-572 | 17.6 x 10-6 | 9.8 x 10-6 |
| 20-500 | 68-932 | 18.6 x 10-6 | 10.3 x 10-6 |
| 20-700 | 68-1292 | 19.5 x 10-6 | 10.8 x 10-6 |
| 20-871 | 68-1600 | 19.8 x 10-6 | 11.0 x 10-6 |
| Temperature Range | Coefficients | ||
|---|---|---|---|
| °C | °F | W/m·K | Btu/(hr/ft²/in/°F) |
| 20-100 | 68-212 | 16.3 | 9.4 |
| 20-500 | 68-932 | 21.4 | 12.4 |
| Temperature Range | J/kg°K | Btu/lb/°F | |
|---|---|---|---|
| °C | °F | ||
| 0-100 | 32-212 | 500 | 0.12 |
H/m Annealed 1.02 Max @ 200 H
| Temperature Range | microhm-cm | microhm-in | |
|---|---|---|---|
| °C | °F | ||
| 20 | 68 | 72 | 28.3 |
| 100 | 212 | 78 | 30.7 |
| 200 | 392 | 86 | 33.8 |
| 400 | 752 | 100 | 39.4 |
| 600 | 1112 | 111 | 43.7 |
| 800 | 1472 | 121 | 47.6 |
| 900 | 1652 | 126 | 49.6 |
| Condition | Tensile Strength, Min. | 0.2% Yield Strength, Min. | Elong. In 2" (50mm) | ||
|---|---|---|---|---|---|
| Ksi | MPa | Ksi | MPa | %, Min. | |
| Annealed | 75 | 515 | 30 | 205 | 40 |
| 1/4 Hard | 125 | 862 | 75 | 517 | 25 |
| 1/2 Hard | 150 | 1034 | 110 | 758 | 18* |
| 3/4 Hard | 175 | 1207 | 135 | 931 | 12* |
| Full Hard | 185 | 1276 | 140 | 965 | 9* |
* Value shown for thickness greater than 0.015 in. (.038mm).
