Product Details:
|
| Commodity: | Stainless Steel Angle Bar | Type: | Angle |
|---|---|---|---|
| Application: | Construction, Construction And Decoration | Special Use: | Valve Steels |
| Model Number: | 304 | Surface: | Pickling |
| High Light: | SS angle bar,equal angle bar |
||
| Product name | Stainless steel angle iron |
| Brand name | Ronsco |
| Standard | ASTM A276 |
| Material | 201,304,316L,1.4301,1.4306,1.4404 |
| Surface | Pickling |
| Application | Construction and decoration |
| Payment term | T/T,L/C,Western Union |
| Delivery time | 3-15 working days after deposit received |
| Specification | |||||
| NO | WIDTH*WIDTH*TK | NO | WIDTH*WIDTH*TK | NO | WIDTH*WIDTH*TK |
| 1 | 25*25*3 | 12 | 60*60*5 | 23 | 75*75*7 |
| 2 | 25*25*4 | 13 | 60*60*6 | 24 | 75*75*8 |
| 3 | 30*30*3 | 14 | 63*63*4 | 25 | 75*75*10 |
| 4 | 30*30*4 | 15 | 63*63*5 | 26 | 80*80*6 |
| 5 | 40*40*3 | 16 | 63*63*6 | 27 | 80*80*8 |
| 6 | 40*40*4 | 17 | 63*63*8 | 28 | 80*80*10 |
| 7 | 40*40*5 | 18 | 70*70*6 | 29 | 90*90*6 |
| 8 | 50*50*3 | 19 | 70*70*7 | 30 | 90*90*8 |
| 9 | 50*50*4 | 20 | 70*70*8 | 31 | 90*90*10 |
| 10 | 50*50*5 | 21 | 75*75*5 | 32 | 90*90*12 |
| 11 | 50*50*6 | 22 | 75*75*6 |
| Chemical Composition(%) | |||||||||||
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | N | Cu | |
| 201 | ≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.060 | ≤0.03 | 16.00~18.00 | 3.5~5.5 | - | - | 0.08 | 1.5 |
| 202 | ≤0.15 | ≤1.00 | 7.5~10.00 | ≤0.060 | ≤0.03 | 17.00~19.00 | 4.0~6.0 | - | ≤0.25 | ||
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 6.00~8.00 | - | |||
| 302 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.03 | 17.00~19.00 | 8.00~10.00 | - | |||
| 304 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 8.00~10.50 | - | |||
| 304L | ≤0.030 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 9.00~13.00 | - | |||
| 310S | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 24.00~26.00 | 19.00~22.00 | - | |||
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 10.00~14.00 | 2.00~3.00 | |||
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 12.00~15.00 | 2.00~3.00 | |||
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 17.00~19.00 | 9.00~13.00 | - | |||
| 430 | ≤0.12 | ≤0.75 | ≤1.00 | ≤0.040 | ≤0.03 | 16.00~18.00 | - | ||||
| 2205 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.030 | ≤0.015 | 22.00~23.00 | 4.5~6.5 | 2.5~3.5 | |||
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | ≤0.035 | ≤0.015 | 24.00~26.00 | 6.00~8.00 | 3.0~5.0 | |||
| 904L | ≤0.02 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.035 | 19.00~23.00 | 23.00~28.00 | 4.0~5.0 | 1.0~2.0 | ||
|
INCONEL 028 |
≤0.03 | ≤1.00 | ≤2.50 | ≤0.030 | ≤0.030 | ≤28.0 | ≤34.0 | ≤4.0 | ≤1.4 | ||
|
MONEL 400 |
≤0.30 | ≤0.5 | ≤2.00 | - | ≤0.024 | - | ≥63.0 | - | ≤34.0 | ||
|
INCONEL 800 |
≤0.10 | ≤1.00 | ≤1.50 | - | ≤0.015 | ≤23.0 | ≤35 | 4.0~5.0 | - | ≤0.75 |
Ti≤0.6 Al≤0.6 |
