EN 10326 Hot Galvanized Coil Steel / Galvanized Iron Steel Sheet In Coil SGCC Z40-Z275

China EN 10326 Hot Galvanized Coil Steel / Galvanized Iron Steel Sheet In Coil SGCC Z40-Z275 supplier
EN 10326 Hot Galvanized Coil Steel / Galvanized Iron Steel Sheet In Coil SGCC Z40-Z275 supplier EN 10326 Hot Galvanized Coil Steel / Galvanized Iron Steel Sheet In Coil SGCC Z40-Z275 supplier

Large Image :  EN 10326 Hot Galvanized Coil Steel / Galvanized Iron Steel Sheet In Coil SGCC Z40-Z275

Product Details:

Place of Origin: China Shanghai
Brand Name: WISCO
Certification: ISO
Model Number: Z275

Payment & Shipping Terms:

Minimum Order Quantity: 5 ton
Price: 750 USD/Ton
Delivery Time: 7 days
Payment Terms: T/T, L/C
Supply Ability: 500 tons
Contact Now
Detailed Product Description
Width: 1000-2000mm Length: 2000-6000mm
Thickness: 0.5-3.0mm Technique: Cold Rolled
Surface Treat: Galvanized, Passivating

EN 10326 hot galvanized Coil steel/galvanized iron steel sheet in coil



Three types of galvanized steel coils



All of our galvanized steel coils are made of Cold Rolled Steel.Cr steel coil products with good finishing and easily formed advantage can be widely used in Automobiles,Refrigerators,Washing machines,Industrial equipments, and all kinds of building materials.

Our compnay can manufacture three types of galvanized steel coils:



• Hot dipped Galvanized steel coil (SGCC,SGCD,SGCE)

Electrogalvanized steel coil (SECC,SECD,SECE)

Hot dipped Galvalume Steel Coil (GL)



Detailed Specification of GI Steel Coil



Type-01:Hot dipped Galvanized Steel Coil



Substrate Cold Rolled Steel Coil
Steel Grade DX51D+Z~DX56D+Z,DC51D,Q195,Q235,Q235A,ST02Z,CS-B,etc
Standard JIS G3302-2007, GB/T2518-2008,ST02Z, DIN EN 10327, ASTM A653
Thickness 0.14mm~1.0mm
Width 600mm~1250mm
Zinc Coating Z40~Z60/ Z80~Z100/ Z120~Z150/ Z275
Spangle regular spangle, minimum spangle
Edge mill edge,cut edge
Surface Treatment Chromated,Oiled,Anti-finger print (N)



Type-02:Electrogalvanized Steel coil



Substrate Cold Rolled Steel Coil
Steel Grade DC01+ZE, SECCN5, CR4, ZStE180BH+ZE,etc
Standard JIS G3302-2007, GB/T2518-2008,DIN EN 10327, ASTM A653
Thickness 0.14mm~1.0mm
Width 600mm~1250mm
Zinc Coating E8,E16,E24,E32
Edge mill edge,cut edge
Surface Treatment Oiled,Phosphate (P),Anti-finger print (N)



Type-03:Hot dipped Galvalume Steel Coil



Substrate Cold Rolled Steel Coil
Thickness 0.14mm~2.0mm
Width 600mm~1250mm
Spangle Regular, Zero
Treatment Skin-passed,Chromated,AFP,Oiled
Quality CQ,DQ,HSLA

Processes of Cold Rolled Coil

Cold rolled production lineis runing in the form of 4 convertible roller in single framework,The material:Lower Carbon steel(CQ,DQ,DDQ),Lower Carbon high tensile steel(Q195,Q235,Q345),SHLA steel,deep drawing steel and IF steel.Cover thickness:0.23~1.50mm,width:600~1250mm.



4 convertible Roller machine

0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint



Name Thicnkess (mm) Width (mm) Coils ID (mm) Side Condition Surface Condition
Cold Rolled Coils (CRC) 0.14~1.0 600~1250 508/610 rolling side bright

0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint

Processes of Hot Dipped Galvanized Steel Coil

Hot Dipped Galvanized Steelis widely used in auto, household electrical appliance, IT, adnvaced building materials industries, etc.The process of producing hot dipped galvanized steel is: Cold Rolled Full Hard - Payoff Reels - Degreasing - Annealing - Zinc Coating - Tension Leveling - Straightedge Forming - Chromeate or Oil.



0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint



Characteristics of the Continuous Galvanizing Line
• Adopt roll-painting-chromated technology, ensure the Cr Free and envirinmentally-friendly process.
• High-level automatic control system ensures the efficiency and product quality.
• Product is able to be well shaped after tension leveling and straight forming.
• GI production line equipped with chromated, oiled and anti-finger print facilities can reach customers' requirements.
• Zinc coating control system and technology imported from France guarantees the uniformity of zinc coating.
• The USS method applied in galvanizing thchnology ensures the high quality of adhesion and surface treatment.

0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint

Processes of Electro Galvanized Steel Coil

0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint

0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint

Pakcage and Shipping

0.18mm thickness hot dipped galvanized steel coils, cold rolled galvanized steel coils, coil steel paint

Hot dipped competitive price good quality galvalume steel coil for constuction



Standard A792/ GB/T2518, JIS G 3302, DIN EN 10142, ASTM A 653
Steel Grade SGLCC, SGCD1, SGCD2, DX51D + AZ
Thickness 0.14-1.0mm
Width 600-1250mm
AZinc coating AZ30-275g/m2
Surface treatment Regular spangle, Chromated, Anti-Fingerprint
Spangle regular,minimized spangle
Coil ID 508/ 610mm
Coil weight 3-8MT or as client's requirement
