Product Details:
|
| Steel Grade: | Alloy Steel | Alloy Or Not: | Is Alloy |
|---|---|---|---|
| Technique: | Hot Rolled,Forged,Cold Drawn | Application: | Structural Steel Bar |
| Type: | Alloy Steel Bar,Carbon Steel Bar | Standard: | ASTM,DIN,GB,AISI,JIS |
| Special Use: | Mold Steel | Shape: | Round |
| Length: | 1--12m | Material: | Die Alloy Steel Round Bars |
| Surface: | Black Or Bright | Surface Treatment: | Black/Peeling/Polishing/Machined |
| Diameter: | 12mm-650mm | Delivery Condition: | Annealed |
| Dimensions: | 8-1500mm | Heat Treatment: | Normalized +Annealed +Quenched + Tempered |
| High Light: | 12CRNI3 Alloy Steel Bar,60MM Alloy Steel Bar,Alloy Steel Forged Bar |
||
EN36/BS970 655M13/AISI 9315/DIN1.5752/GB 12CRNI3 Alloy Steel bar
Low temperature toughness, small notch sensitivity
After the steel quenching tempering at low temperature or high temperature tempering has good comprehensive mechanical properties, good low temperature toughness of steel, the notch sensitivity, machinability is good, when the hardness is HB260 ~ 320 ~ 70 in addition, the relative cutting processability was 60% steel annealing at low hardness, plasticity is good, therefore, either by adopting the method of machining manufacturing mold, Cold extrusion molding can also be used to manufacture molds. In order to improve the wear resistance of the mold cavity, the mold needs to be carburized after forming, and then quenching and low temperature tempering, so as to ensure that the surface of the mold has high hardness, high wear resistance and the core has good toughness, the steel is suitable for manufacturing large and medium-sized plastic mold. But the steel has the tendency of tempering brittleness and forming white spots.
Senior carburizing steel is used widely, compared with 15 cr, 20 cr steel, the strength, plasticity, high hardenability.Mainly used to make heavy load conditions require high strength, high hardness and high toughness toughness high spindle and requirements of center or under impact load, small surface wear resistance, heat treatment deformation of shaft, rod and working under high speed and impact load of all kinds of transmission gear, screw, camshaft
Standards:ASTM,JIS,GB,EN(DIN,BS,NF) Or Per as clients’ requires.
1.Chemical Composition and Mechanical Properties(In Quenched & Tempered State):
| Material | EN36 | ||
| Chemical Composition | Mechanical Properties(In Quenched & Tempered State) | ||
| C | 0.1-0.17 | Tensile strength(MPA) | ≥930 |
| Si | 0.17-0.37 | Yield strength (MPA) | ≥685 |
| Mn | 0.30-0.60 | Elongation(δ5/%) | 11 |
| Cr | 0.60-0.90 | Reduction in Area (ψ/%) | 55 |
| Mo | Impact (J) | ||
| P | ≤0.035 |
Hardness |
|
| S | ≤0.035 | ||
| Cu | |||
| Ni | 2.75-3.15 | ||
2.Product Application Areas:
Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical industry,
electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.
3.Similar steel grade & equivalent steel materials:
Product Sales Information:
| Material | EN36 steel round bar |
| Size |
Diameter:20mm-1000mm Length:500mm-6000mm |
| Origin place | Made In China |
| Delivery Condition | Hot rolled,cold drawn,forged |
| Surface require | Black,grinding,bright,polish |
| Heat treatment | Quenched,Tempered,annealed |
| Packing | seaworthy packing ,wooden case ,carton,woven bag or at client's requires |
| Delivery time | In 10-50 days |
| Trade Term | EXW,FOB,CIF |
| Payments | T/T or L/C at sight |
| Port | China main Port,such as shanghai,Dalian,Shenzhen port. |
| MOQ | 1 Ton |
Company Main Products:
| Alloy Steel |
4140,4142,42CrMo4,1.7225,SCM440,4130,SCM430,25CrMo4,1.7218,34CrNiMo6, 1.6582,4340,SNCM439,36CrNiMo4,1.6511,SACN645,1340,SMn438,SNC236, |
| Tool Steel |
H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419, SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2 |
| Bearing Steel | GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50 |
| Spring Steel |
9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150, SUP10,51CrV4,1.8159 |
| Stainless Steel |
321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028, 434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057, |
