Hastelloy C276 Bar Hastelloy C276 Nickel Alloy Bar Nickel Alloy C276/ Inconel C276/ Hastelloy C276 (AMS 5750)- Bar

Nickel Alloy C-276/Hastelloy® C-276 Bar

UNS N10276

Nickel Alloy C-276 and Hastelloy® C-276, commonly known as UNS N10276, is generally considered the most versatile corrosion resistant alloy available, comprised of nickel, molybdenum, chromium, iron and tungsten. These elements combined results outstanding corrosion resistant properties particularly crevice and pitting, allowing for its use in a broad range of corrosive environments. It displays tremendous resistance to many acids, including sulfuric, acetic, phosphoric, formic, nitric, hydrochloric, and hydrofluoric compounds, which is why it is so popular in chemical and food processing environments including strong oxidizers.

Nickel Alloy C-276 is a fairly normal alloy in the sense that it can be impact extruded, forged and hot upset forged by conventional means. It has good machineability as it can be successfully press formed, spun, punched or deep-drawn; however it does have a tendency to work harden as is true of the nickel base alloys in general. It can be welded by all common methods such as gas metal-arc, resistance welding, gas tungsten-arc or shielded metal-arc. Applying minimum heat input combined with sufficient penetration can reduce hot cracking to avoid the possibility of carburization. Two methods that are not recommended are submerged arc welding and oxyacetylene welding when the component is to be used in a corrosive environment. A welding advantage of Nickel Alloy C-276 is that it can be used in the “as-welded” condition without further heat treatment for most corrosive applications.

Industries that use C-276 include:

• Chemical process
• Food processing
• Petrochemical
• Pollution control
• Pulp and Paper
• Refining
• Waste treatment facilities

Products partially or completely constructed of C-276 include:

• Acoustic pressure sensors
• Ball valves
• Centrifugal pumps
• Check valves
• Crushers
• Desulfurization of flue gas equipment
• Flow meters
• Gas sampling
• Heat exchangers
• Process engineering probes
• Secondary containment chambers
• Tubes
