EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500

EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500
EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500 EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500 EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500

Large Image :  EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500

Product Details:
Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO MTC
Model Number: 430
Payment & Shipping Terms:
Minimum Order Quantity: 5000KGS
Price: 1.85 USD/KG
Packaging Details: Wooden Pallet BOX
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 80000KGS

EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500

Description
Application: Construction Width: 1000-2000mm
Type: Stainless Steel Sheet Standard: ASTM
Length: 1000-6000mm Or Customer's Requirement Grade: 400 Series
Surface: BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D Thickness: 0.45-5mm
Edge: Slit Edge,Mill Edge Technique: Cold Rolled Finish
Price Term: CIF CFR FOB EX-WORK
High Light:

stainless steel metal sheet

,

stainless steel panels

Finish BA cold rolled 430 stainless steel coils 0.3-1.2mm
Quick detail:

Description:430 stainless steel sheet in coils/430 Cold rolled stainless steel coils

Grade: SUS430 1.4016 S43000

Thickness: 0.3-1.2mm

Finish: BA

Width:1000 1030 1250 1550 1500

Standard: JIS EN ASTM AISI

Coil ID: 508/610mm

Paper Interleaved: Yes



Main Specification

Description 430 stainless steel sheet in coils/430 Cold rolled stainless steel coils/CR stainless steel sheet in coils
Grade SUS430 1.4016 S43000
Thickness 0.3-3.0mm
Finish 2B BA No.3 No.4 HL PE/PVC
Width 1000-1550mm
Standard JIS EN ASTM AISI
Coil ID 508/610mm
Thickness tolerance to be defined with customers
Q'ty tolerance +/-10% on order quantity
Paper Interleaved Yes
Country of Origin made in China
Packaging Seaworthy standard export package with pallet:
·Paper interleaved
·Horizontal straps+vertical straps
·External metal or cardboad protection
·Pallet is including





CHEMICAL COMPOSITION&Mechanical properties

STANDARD GRADE CHEMICAL COMPOSITION(%)
C max Si max Mn max P max S max Ni Cr
JIS SUS430* 0.12 0.75 1.00 0.040 0.030 - 16.00~18.00
GB 1Cr17 0.12 1.0 1.00 0.040 0.030 0.75 16.00~18.00
ASTM S43000* 0.12 1.0 1.00 0.040 0.030 0.75 16.00~18.00
EN 1.4016 0.08 1.0 1.00 0.040 0.015 - 16.00~18.00
Mechanical properties
Yield Strength Tensile Strength Elongation Hardness
(N/mm2) (N/mm2) (%) HRB HV
≥205 ≥420 ≥22 ≤80 ≤200






EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500 0EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500 1EN 1.4511 AISI 430 NB 1MM Stainless Steel Sheet Metal 1000X2000 / 1250X2500 2
