Product Details:
|
| Application: | Construction,Decoration,Industry,boiler,Chemical | Standard: | DIN,ASTM,JIS |
|---|---|---|---|
| Steel Grade: | 304 304L 316 316L 310S 321 | Type: | Seamless |
| Thickness: | 1-95mm | Shape: | Round.square.Rectangle |
| Outer Diameter: | 6-762mm | Technique: | Cold Drawn |
| High Light: | seamless stainless steel tube,ss seamless pipes |
||
Pipe Stainless Steel ASME B16.10 ASTM A312-TP304L Stainless Steel Seamless Tube
MITTEL STEEL produces and supplies ASTM A312 products in welded and seamless tubes and pipes. Stainless steel pipe ASTM A312 has 4 main grades TP304/304L, TP316/316L. TP304/TP304L and TP347 are included in ASME pressure vessel code and the Chemical Plant and Refinery Piping Code, These steel tubes are safe to be used in temperatures as low as −425 °F [−250 °C] without impact tests qualification.
ASTM A312 covers seamless and straight-seam welded austenitic pipe intended for high temperature and general corrosive service. Steel pipe of ASTM A312 should be marked with the following info: Pipe size, wall thickness, specification, grade, seamless or welded, heat number, etc. Welded pipe of ASTM A312 should not use filler metal in automatic welding, large diameter pipe may have 2 longitudinal welds, pipe can be hot finished or cold finished. ANSON is an experienced boiler and pressure steel tube supplier which can offer you ASTM A312 steel pipe of all grade and dimension range.
| Steel Grade | ASTM A312 Chemical Composition % Max | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| C | Mn | P | S | Si | Cr | Ni | Mo | N B | Nb | Ti | |
| TP304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0-20.0 | 8.0-11.0 | … | … | … . | … |
| TP304H | 0.04-0.10 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0-20.0 | 8.0-11.0 | … | … | … | … |
| TP304L | 0.035 D | 2.00 | 0.045 | 0.030 | 1.00 | 18.0-20.0 | 8.0-13.0 | … | … | … | … |
| TP310S | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 24.0-26.0 | 19.0-22.0 | 0.75 | |||
| TP316 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | … | … | … |
| TP316L | 0.035 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | … | … | … |
| TP316H | 0.04-0.10 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 | … | … | … |
| TP316Ti | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | 0.10 | … | 5x(C+N)-0.70 |
| TP321 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0-19.0 | 9.0-12.0 | … | 0.10 | … | 5C-0.70 |
| TP321H | 0.04-0.10 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0-19.0 | 9.0-12.0 | … | … | … | 4C-0.60 |
| TP347 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0-19.0 | 9.0-13.0 | 10xC-1.00 | … | ||
| TP347H | 0.04-0.10 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0-19.0 | 9.0-13.0 | … | … | 8xC-1.00 | … |
| ASTM A312 Mechanical Properties | |||||
|---|---|---|---|---|---|
| Steel Grade | Heat Treatment |
Temperure Min. º F(º C) |
Tensile Strength Ksi (MPa), Min. |
Yield Strength Ksi (MPa), Min. |
Elongation %, Min |
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP304H | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP310S | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
| TP316H | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316Ti | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP321 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP321H | Solution | Cold: 2000(1100) Hot: 1925(1050) |
75(515) | 30(205) | 35 |
| TP347 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP347H | Solution | Cold: 2000(1100) Hot: 1925(1050) |
75(515) | 30(205) | |
| ASTM A312 | JIS G3459 | DIN 17440 | BS | NF |
|---|---|---|---|---|
| TP304 | SUS 304 TP | X5CrNi 18 9 | 304S18 | A 49-230 |
| TP304H | SUS 304 HTP | 304S59 | A 49-214 | |
| TP310 | 304 LTP | X2 CrNi 19 9 | 304S14 | A 49-230 |
| TP316 | SUS 304L TP | |||
| TP316H | 310STP | X5 CrNiMo 18 10 | 316S18 | A 35-573 |
| TP316L | SUS 316 TP | 316S59 | A 49-230 | |
| TP321 | SUS 316 LTP | X2 CrNiMo 18 10 | 316S14 | A 49-230 |
| TP347 | 316 HTP | x10 CrNiTi 18 9 | 321S18 | A 49-230 |
| TP347H | SUS 316 LTP | X5 CrNiNb 18 9 | 347S18 | A 35-573 |
MITTEL can supply ASTM A312 steel tube from stock or from reputed steel mills. We also offer steel fabrication service where steel plates can go through processings like cutting, welding, bending, machining, pre-coating, pre-lined, beveling, or as you require. Our steel mills have fabricating employees that have 5-10 years of working experience. If you are interested in buying ASTM A312 steel tube products, contact us now for the latest price or check the following table for equivalent steel grade of ASTM A312.
| NPS | ASTM A312 WT Tolerance, % | |
|---|---|---|
| + | – | |
| 1/8-2 1 /2 | 20.0 | 12.5 |
| 3~18, t/D≤ 5% | 22.5 | 12.5 |
| 3~18, t/D> 5% | 15.0 | 12.5 |
| ≥ 20, welded | 17.5 | 12.5 |
| ≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
| ≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
| NPS | ASTM A312 OD Tolerance | |||
|---|---|---|---|---|
| + | – | |||
| inch | mm | inch | mm | |
| 1/8~1 1 /2 > 1 1 /2~4 > 4~8 > 8~18 > 18~26 > 26~34 > 34~48 |
1/64(0.015) 1/32(0.031) 1/16(0.062) 3/32(0.093) 1/8(0.125) 5/32(0.156) 3/16(0.187) |
0.4 0.8 1.6 2.4 3.2 4.0 4.8 |
1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) |
0.8 0.8 0.8 0.8 0.8 0.8 0.8 |
