Raw Forged SS 316 Round Bar To Be Machined As Propeller Shaft Annealed And Rough Peeled

Raw Forged SS 316 Round Bar  To Be Machined As Propeller Shaft Annealed And Rough Peeled
Raw Forged SS 316 Round Bar  To Be Machined As Propeller Shaft Annealed And Rough Peeled Raw Forged SS 316 Round Bar  To Be Machined As Propeller Shaft Annealed And Rough Peeled

Large Image :  Raw Forged SS 316 Round Bar To Be Machined As Propeller Shaft Annealed And Rough Peeled

Product Details:
Place of Origin: China
Brand Name: TSINGSHAN
Certification: SGS ISO MTC BV
Model Number: 316L
Payment & Shipping Terms:
Minimum Order Quantity: 50KGS
Price: 3.65USD/KG
Packaging Details: Standard Seaworthy Package
Delivery Time: 7 Days after Received the Payments
Payment Terms: L/C, T/T
Supply Ability: 500Tons

Raw Forged SS 316 Round Bar To Be Machined As Propeller Shaft Annealed And Rough Peeled

Description
Type: Round Application: Construction,decoration,Industry,Mechineal,shipbuilding
Standard: DIN,ASTM Grade: 300 Series
Certification: ISO,BV,SGS Dimensions: 5.5mm-500mm
Surface: Bright,Polished Technique: Cold Rolled Hot Rolled
Length: Customers' Requirements Packing: Standard Seaworthy Package
Price Term: CIF CFR FOB Ex-Work
High Light:

ss round bars

,

stainless steel round rod



Alloy 316/316L is molybdenum-bearing austenitic stainless steel. The higher nickel and molybdenum content in this grade allows it to demonstrate better overall corrosion resistant properties than 304, especially with regard to pitting and crevice corrosion in chloride environments. In addition, Alloy 316/ 316L provides excellent elevated temperature tensile, creep and stress-rupture strengths, as well as outstanding formability and weldability. 316L is the lower carbon version of 316 and is immune from sensitization; therefore, it is very frequently used in heavy gauge welded components.

Specifications: UNS S31600 / S31603

Applications:

  • Food preparation equipment, especially in chloride environments
  • Chemical processing, equipment
  • Laboratory benches and equipment
  • Rubber, plastics, pulp & paper machinery
  • Pollution control equipment
  • Boat fittings, value and pump trim
  • Heat exchangers
  • Pharmaceutical and textile industries
  • Condensers, evaporators and tanks

Standards:

  • ASTM/ASME: UNS S31600 / S31603
  • EURONORM: X1 CrNiMo 17 12 2 / X3 CrNiMo 17 12 2
  • AFNOR: Z 6 CND 17-11 / Z 2 CND 17-12
  • DIN: 1.4401 / 1.4404



Corrosion Resistance:

  • Generally more resistant than 304 in range of atmospheric environments and many corrosive media due to the increased chromium
    and molybdenum content.
  • Subject to pitting and crevice corrosion in warm chloride environments, and to stress corrosion cracking above about 122°F (50°C).
  • Considered resistant to potable water with up to about 1000mg/L chlorides at ambient temperatures, reducing to about 500mg/L at
    140°F (60°C).
  • Usually regarded as the “marine grade stainless steel” – but is not resistant to warm sea water.

Heat Resistance:

  • Good oxidation resistance in intermittent service to 1600°F (870°C) and in continuous service to 1700°F (925°C)
  • Grade 316L is more resistant to carbide precipitation.





Welding Characteristics:

  • Excellent weldability by all standard fusion methods, both with and without filler metals.
  • Heavy welded sections in Grade 316 require post-weld annealing for maximum corrosion resistance, this is not required for grade 316L.

Heat Treatment:

  • Annealing temperature range is 1900 to 2100°F (1038 to 1149°C).
  • Cannot be hardened by heat treatment.
  • Special consideration is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion.

Processing – Hot Forming:

  • Most producers recommend a maximum forging temperature between 2100°F and 2300°F
  • Do not forge below 1700°F (927°C) Best
  • Corrosion resistance is obtained if the forgings are given a final anneal.

Processing – Cold Forming:

  • 316/316L types being extremely tough and ductile, can be readily cold worked such as roll form, swaging, cold heading, deep drawing,
    bent, etc., without difficulty
  • Severely cold formed parts should be annealed to remove stresses.

Machineability:

  • Type 316/316L is somewhat more difficult to machine than Type 304 because of its toughness.
  • 316/316L machines with chip characteristics that are tough and strong.
  • Chip breakers and curlers are advised.
  • As large a tool as possible and great amounts of cutting fluid should be used.
  • Heavy positive feeds at low speeds should be considered since 316/316L work hardens rapidly.



Chemical Properties:

  C Mn Si P S Cr Mo Ni N
316
(S31600)
0.08
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max
316L
(S31603)
0.03
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max

Mechanical Properties:

Grade Tensile Strength
ksi (min)
Yield Strength
0.2% ksi (min)
Elongation % Hardness (Brinell) MAX Hardness
(Rockwell B) MAX
316
(S31600)
75 30 40 217 95
316L
(S31603)
70 25 40 217 95

Physical Properties:

Density
lbm/in3
Thermal Conductivity
(BTU/h ft. °F)
Electrical
Resistivity
(in x 10-6)
Modulus of
Elasticity
(psi x 106
Coefficient of
Thermal Expansion
(in/in)/°F x 10-6
Specific Heat
(BTU/lb/°F)
Melting
Range (°F)
0.29 at 68°F 100.8 at 68 212°F 29.1 at 68°F 29 8.9 at 32 – 212°F 0.108 at 68°F 2500 to 2550
        9.7 at 32 – 1000°F 0.116 at 200°F
        11.1 at 32 – 1500°F



Raw Forged SS 316 Round Bar  To Be Machined As Propeller Shaft Annealed And Rough Peeled 0Raw Forged SS 316 Round Bar  To Be Machined As Propeller Shaft Annealed And Rough Peeled 1
