Product Details:
|
Grade: | 316L | Application: | Engineering Structure,Construction,telecome,building |
---|---|---|---|
Type: | Equal And Unequal | Standard: | ASTM,JIS,AISI,DIN |
Length: | 1-12m | Technique: | Hot Rolled |
Product Name: | Asi Ss 316 Ss 304 304L Stainless Steel Equal Angle Bar | Dimensions: | 20*20mm*3mm-250x250x35mm |
Surface Treatment: | NO.1 | Shape: | Equilateral Angle Bar,Equal Unequal |
Package: | Standard Sea-worthy Packing | Keywords: | Stainless Steel Angle |
Sample: | For Free | ||
High Light: | SS angle bar,equal angle bar |
Stainless Steel Angle Bar 316L Hot Rolled SS316L Angle Bar
Main Specification
Description | Stainless steel angle bar |
Grade | 304 321 316L |
Thickness | 3-12mm |
Finish | No.1 |
Size | 3*25*25-12*150*150mm |
Torelance | According to GB4227,ASTMA276/A484M,EN10056/DIN1028 |
Grade | Prime |
Country of Origin | made in China |
Payment terms | by T/T or L/C |
Packaging | Seaworthy standard export package with pallet |
Shipping date | one month |
Shipping terms | FOB CFR CIF etc. |
Thoretical Weigth Reference
Dimensions(mm) | Weight(kg/m) | Dimensions(mm) | Weight(kg/m) |
20x20x3 | 0.88 | 60x60x5 | 4.58 |
25x25x3 | 1.12 | 60x60x6 | 5.42 |
25x25x5 | 1.77 | 65x65x5 | 5.03 |
30x30x3 | 1.36 | 65x65x6 | 5.84 |
30x30x4 | 1.78 | 75x75x5 | 5.82 |
30x30x5 | 2.17 | 75x75x6 | 6.89 |
40x40x3 | 1.88 | 75x75x9 | 10.00 |
40x40x4 | 2.42 | 80x80x8 | 9.66 |
40x40x5 | 2.97 | 100x100x6 | 9.28 |
40x40x6 | 3.52 | 100x100x8 | 12.40 |
50x50x3 | 2.36 | 100x100x10 | 15.10 |
50x50x4 | 3.07 | 100x100x12 | 17.80 |
50x50x5 | 3.77 | 120*120*10 |
|
50x50x6 | 4.40 | 150*150*10 |
1) The appearance of the product is good and beautiful;
2) Due to the additional of Mo, corrosion resistance, especially excellent resistance to pitting corrosion;
3) Excellent high temperature strength;
4) Excellent work hardening (weak magnetic after processing)
5) Non-magnetic in solid solution state;
316 stainless steel angle bar
Features: 316 stainless steel is the second most widely used steel grade after 304. It is mainly used in food industry and surgical equipment. Due to the addition of Mo, its corrosion resistance, atmospheric corrosion resistance and high temperature strength are particularly good. Can be used under harsh conditions; excellent work hardening (non-magnetic).
