Home ProductsSeamless Steel Pipe

Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water

Certification
Good quality Stainless Steel Plates for sales
Good quality Stainless Steel Plates for sales
this is the second order l buy this company ,quality is very good ,same as europure quality .we will go on ccooperate with this company .

—— Andrew Greg - Turkey

200 ton Stainless steel sheet is arrived on 10th Oct 2014 , the quality is very good.,deliver time is very fast It's very lucky we find this factory

—— Mechile Kilar Chard - Brazial

We Have Cooperate With this Factory Many Years , Everything Goes Very Well.l Like This Factory !

—— Tony Hilton - Poland

This is Our Thrid Time Buy from Mittel,Quality is Very Goods ,We Are Glad to Find This Reliable Factory

—— Natalya Ugay-Russia

Quality is very good and delivery time very fast ,we want to do long terms business with this company

—— Pongpol Pluemsati-Thailand

I'm Online Chat Now

Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water

China Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water supplier
Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water supplier Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water supplier Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water supplier Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water supplier Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water supplier

Large Image :  Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water

Product Details:

Place of Origin: China
Brand Name: Mittel
Certification: SGS ISO
Model Number: ASTM A53

Payment & Shipping Terms:

Minimum Order Quantity: 1 Ton
Price: 750 USD/Ton
Packaging Details: Export Packing
Delivery Time: 14 Days
Payment Terms: L/C, T/T
Supply Ability: 5000Tons
Contact Now
Detailed Product Description
OD: 19-325mm Thickness: 0.5-10mm
Surface: Galvanized Steel Length: 6000mm
Coating: Z150g Type: Seamless And Welded

Galvanized Steel Scaffold Tube Galvanized Steel Welded Water Tube Galvanized Steel Pipe For Drinking Water

Product Name
galvanized steel pipe

Size
W.T. 0.5mm-20.0mm
Diameter 15-219.10mm
Length 6m, 12m or as per your requirements
Sample
Sample Avaliable
Surface
hot dipped galvanized ,per-galvanized,painted,oiled and etc,
Payment terms
30%T/T in advance,balance 70% after receiving the copy of BL.
Certificate test
we offer MTC (mill test certification)
Stock or not
enough stock
Inspection
With Chemical Composition and Mechanical Properties Testing; Hydrostatic Test, Dimensional and Visual Inspection, With Nondestructive Inspection
Packing
In bundles, bulk in container or according to customers' requirements length>12m,shipped in bulk; 5.8m<length<11.8m, shipped in 40'containers;
length<5.8m ,shipped in 20' or 40'containers
Delivery time
10-25 days after we received your advanced deposit.
Others
1.special design available according to requirment
2.anti-corrosion and high-temperature resistant with black painting.
3.all the production process are made under the ISO9001:2000 strictly.and CE certificate





Finish of pipe:



Hot dipped galvanized with zinc 200~260g/m2;

Pre-Galvanized with zinc 30~150g/m2

Painted with black/varnish lacquer;

Oil on the surface to prevent rust;

Bare pipe without painting:

Epoxy painting/FBE coating/3PE coating



SURFACE TREATMENT: Galvanized both sides, zinc coating: 120-



160G/M2

W. T tolerance: +/- 0.05mm

OD. Tolerance: +/- 0.05mm



Other Details:



processing method: cold roll forming with ERW welding



material: Low carbon hot rolled coils



steel grade: Q235B~345B



surface treatment: hot dip galvanizing



Application: liquid transmission and all kinds of steel structure purpose.



Galvanized steel pipe produce:



Hot dip galvanized steel pipe with pickling, first to remove iron oxide on the surface of



the steel tube, after acid cleaning, by ammonium chloride or zinc chloride or ammonium



chloride and zinc chloride mixed aqueous solution tank cleaning, and then sent to the



hot dip plating tank. Hot dipped galvanized zinc layer thickness, coating uniformity,



strong adhesion, long service life, etc. Steel substrate with molten electrolyte solution in



complex physical and chemical reaction, the formation of corrosion resistance of the



structure compact zinc alloy layer. Pure zinc layer, alloy layer and steel substrate fused



together .erw / lsaw spiral welded steel high quality galvanized pipe prices and



manufacturers



The detailed size is as following:



Hot dipped galvanized pipe
Outside Diameter Wall Thickness
DN Inch mm mm
15 1/2" 20~21.3 0.95~2.77
20 3/4" 25~26.9 1.1~2.87
25 1" 32~33.7 1.1~4.0
32 1 1/4" 40~42.4 1.1~4.0
40 1 1/2" 47~48.3 1.5~7.0
50 2" 58~60.3 1.8~7.0
65 2 1/2" 73~76.1 2.0~7.0
80 3" 87~88.9 2.2~8.0
90 3 1/2" 101.6~102.1 2.2~9.0
100 4" 113~114.3 2.2~9.0
125 5" 140~141.3 2.5~10.0
150 6" 165~168.3 2.5~10.0
200 8" 216~219.1 2.75~12.0

 Galvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking WaterGalvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking WaterGalvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking WaterGalvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking WaterGalvanized Steel Scaffold Tube Welded Water Tube Galvanized Steel Pipe For Drinking Water
