Product Details:
Place of Origin: China
Brand Name: WU Steel
Certification: SGS ISO
Model Number: ASME SA516 GR 70
Payment & Shipping Terms:
Minimum Order Quantity: 2 Tons
Price: 815 USD/Ton
Packaging Details: Export Packing
Delivery Time: 14 Days
Payment Terms: L/C, T/T
Supply Ability: 1000Tons

ASME SA516 GR 70 Plate Boiler And Pressure Vessel Hot Rolled Astm A516 Gr 70 Mechanical

Description
Thickness: 3-150mm Width: 1000-3000mm
Length: 2000-12000mm Type: Plate
Condtion: Hot Rolled
High Light:

high strength steel plate

,

hot rolled steel plate

ASME SA516 GR 70 Plate Boiler and Pressure Vessel Hot Rolled Astm A516 Gr 70 Mechanical Specifications



  •
  •

ASME SA516 standard specification for pressure vessel plates, carbon steel for moderate and lower- temperature service.

ASME SA516 plates 40mm and under in thickness is normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both. ASME SA516 grade plates over 40mm in thickness shall be normalized.



Supplementary Technology: HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1
S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17



Thickness: 6MM to 300MM,

Width: 1500mm to 4050mm,

Length: 3000mm to 15000mm

Gangsteel is specialized in supplying ASME SA516 steel plate in SA516 grade 70. For more information of SA516 grade 70 steel plates, please check them in following:





SA516 Grade 70 Chemical Composition

Grade

SA516 grade 70

The Element Max (%)
C Si Mn P S
Thick <12.5mm 0.27 0.13-0.45 0.79-1.30 0.035 0.035
Thick12.5-50mm 0.28 0.13-0.45 0.79-1.30 0.035 0.035
Thick50-100mm 0.30 0.13-0.45 0.79-1.30 0.035 0.035
Thick100-200mm 0.31 0.13-0.45 0.79-1.30 0.035 0.035
Thick>200mm 0.31 0.13-0.45 0.79-1.30 0.035 0.035

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%







Grade SA516 Grade 70 Mechanical Property
Thickness Yield Tensile Elongation
SA516 grade 70 mm Min Mpa Mpa Min %
6-50 260 485-620 21%
50-200 260 485-620 17%

Shipbuilding steel plate| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate







Equivalent steel grade of SA516 grade 70
Europe Belgium Germany France Italy Sweden India Japan
    E St E315   Fe 460-2-KG SS29,12,01



If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.
