Product Details:
|
| Width: | 1000-2500mm | Length: | 2000-6000mm |
|---|---|---|---|
| Thickness: | 1.5-50mm | Surface: | 2B,NO.1 |
| Type: | Prime Grade | Technique: | High Temperature Resistant |
| Highlight: | precision ground stainless steel plate,stainless steel plate thickness |
||
S32750 Super Duplex Stainless Steel Plate DIN 1.4410 Metal Flat Plate 0.5-50mm Width1000-2000mm
|
Product Details |
|
|
Product name |
Stainless steel sheet |
|
Brand name |
MITTEL |
|
Standard |
ASTM A240, ASTM A480, EN10088, JIS G4305 |
|
Material |
304, 316L, 321, 310S, 1.4301, 1.4307, 1.4404, S31803, S32750, 904L, Monel 400, Inconel 800 |
|
Surface |
NO.1,2B,NO.4,BA,SB,Satin,Brushed,Hairline,Mirror |
|
Payment term |
T/T,L/C,Western Union |
|
Packing |
In wooden cases,in wooden pallets |
|
Shipment |
By sea, by air, by express |
|
Specifications |
|
Chemical Composition(%) |
|||||||||||
|
Grade |
C | Si | Mn | P | S | Cr | Ni | Mo | N | Cu | |
|
201 |
≤0.15 | ≤0.75 | 5.5~7.5 | ≤0.060 | ≤0.03 | 16.00~18.00 | 3.5~5.5 | - | - | 0.08 | 1.5 |
| 202 | ≤0.15 | ≤1.00 | 7.5~10.00 | ≤0.060 | ≤0.03 | 17.00~19.00 |
4.0~6.0 |
- | ≤0.25 | ||
| 301 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 6.00~8.00 | - | |||
| 302 | ≤0.15 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.03 | 17.00~19.00 | 8.00~10.00 | - | |||
| 304 | ≤0.07 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 8.00~10.50 | - | |||
| 304L | ≤0.030 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 18.00~20.00 | 9.00~13.00 | - | |||
| 310S | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 24.00~26.00 | 19.00~22.00 | - | |||
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 10.00~14.00 | 2.00~3.00 | |||
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 16.00~18.00 | 12.00~15.00 | 2.00~3.00 | |||
| 321 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 17.00~19.00 | 9.00~13.00 | - | |||
|
430 |
≤0.12 | ≤0.75 | ≤1.00 | ≤0.040 | ≤0.03 | 16.00~18.00 |
|
- | |||
| 2205 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.030 | ≤0.015 | 22.00~23.00 | 4.5~6.5 | 2.5~3.5 | |||
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | ≤0.035 | ≤0.015 | 24.00~26.00 | 6.00~8.00 | 3.0~5.0 | |||
| 904L | ≤0.02 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.035 | 19.00~23.00 | 23.00~28.00 | 4.0~5.0 |
1.0~2.0 |
||
|
INCONEL 028 |
≤0.03 | ≤1.00 | ≤2.50 | ≤0.030 | ≤0.030 | ≤28.0 | ≤34.0 | ≤4.0 | ≤1.4 | ||
|
MONEL 400 |
≤0.30 | ≤0.5 | ≤2.00 | - | ≤0.024 | - | ≥63.0 | - | ≤34.0 | ||
|
INCONEL 800 |
≤0.10 | ≤1.00 | ≤1.50 | - | ≤0.015 | ≤23.0 | ≤35 | 4.0~5.0 | - | ≤0.75 |
Ti≤0.6 Al≤0.6 |
Cold rolled,annealing,pickled,slited,straightened,for stainless steel plate raw material
Stainless steel maintenance:
(1) Regular cleaning and maintenance
(2) Pay attention to prevent the occurrence of the phenomenon of surface scratches
(3) Use soap, weak detergent or warm water to remove surface dust, dirt
(4) In addition to the surface of the binder with alcohol or an organic solvent (ether, benzene)
(5) Use neutral detergent or ammonia solution in addition to surface oil
(6) With 10% nitric acid or abrasive detergent in addition to the surface of the embroider caused by the dirt.
Mill test certificate--stainless steel sheet
Application--stainless steel sheet/plate
Stainless steels of various kinds are used in thousands of applications. The following gives a flavour of the full range:
1.Domestic – cutlery, sinks, saucepans, washing machine drums, microwave oven liners, razor blades
2.Transport – exhaust systems, car trim/grilles, road tankers, ship containers, ships chemical tankers, refuse vehicles
3.Oil and Gas – platform accommodation, cable trays, subsea pipelines.
4.Medical – Surgical instruments, surgical implants, MRI scanners.
5.Food and Drink – Catering equipment, brewing, distilling, food processing.
6.Water – Water and sewage treatment, water tubing, hot water tanks.
7.General – springs, fasteners (bolts, nuts and washers), wire.
8.Chemical/Pharmaceutical – pressure vessels, process piping.
9.Architectural/Civil Engineering – cladding, handrails, door and window fittings, street furniture, structural sections,reinforcement bar, lighting columns, lintels, masonry supports
