Product Details:
|
Thickness: | 0.5-20MM | Width: | 1000-2000mm |
---|---|---|---|
Length: | 2000-8000mm | Surface: | 2B,NO.1,8K |
Type: | Cold Rolled | Application: | Construction Field ,ships Building |
Highlight: | stainless steel metal sheet,stainless steel panels |
Commodity | 304 stainless steel sheet DIN 1.4301 1.2*12500*2500 Metal Sheet With PE Film | ||||||||
Width | 1000mm/1219mm/1240mm/1500mm/2000mm or as customer’s requirements. | ||||||||
Thickness |
Cold rolled:0.3-3.0mm Hot rolled:3mm-150mm |
||||||||
Length | 1000mm to 6000mm or as customer's request | ||||||||
Surface | No.1,2b,8k,2d,Ba,No.4,No.6,No.8, etc. | ||||||||
Material |
304 |
||||||||
Grade | 300series | ||||||||
Standards | AISI ASTM JIS SUS and GB | ||||||||
Certifications | ISO 9001and SGS | ||||||||
Applications |
Kitchenware, utensils, tableware, household appliances, construction decoration and daily products |
||||||||
Packing |
1.with wooden pallets, or film covered, in the containers. 2.Export standard package or as the customers' demands. 3.seaworthy wooden cases. 4.with or without edge protector,steel hoop and seals. 5.export -ted standard package or as customers signal requirement. |
||||||||
Place of origin | Shanxi China (mainland) | ||||||||
Payment terms |
1.30%T/T in advance ,the balance against the B/L copy 2.30%T/T in advance,the balance be paid by L/C at sight |
||||||||
Delivery time | 3-7days |
Surface Treatment:
Finish |
Thickness |
Characteristics |
Applications |
No. 1 |
3.0mm~150.0mm |
Finished by hot-rolling, annealing and pickling, characterized by white pickled surface |
Chemical industry equipment, Industrial tanks |
2B |
0.3mm~6.0mm |
Finished by heat treatment, pickling after cold rolling, followed by skin pass line to be more brighter and smooth surface |
General Application Medical Instruments,Tableware |
BA (BrightAnnealed) |
0.5mm~2.0mm |
Bright heat treatment after cold rolling |
Kitchen utensil, kitchen ware,architectural purpose |
No. 4 |
0.4mm~3.0mm |
Polishing with No. 150 to No.180 mesh abrasivesThe most popular finishes |
Milk & Food processing acilities, Hospital Equipment, Bath-tub |
HL (Hair Line) |
0.4mm~3.0mm |
Finished by continuous linear polishing |
Architectural purposes, escalators, kitchen ware vehicles |
Chemical Composition and Physical Properties :
Table 1. Typical chemical composition for 304 stainless steel sheet
% |
304 |
304L |
304H |
C |
0-0.07 |
0-0.03 |
0.04-1 |
Mn |
0-2.0 |
0-2.0 |
0-2.0 |
Si |
0-1 |
0-1 |
0-1 |
P |
0-0.05 |
0-0.05 |
0-0.05 |
S |
0-0.02 |
0-0.02 |
0-0.02 |
Cr |
17.5-19.5 |
18.0-20.0 |
17.5-19.5 |
Ni |
8-10.5 |
9.0-13.0
|
8-10.5 |
Fe |
Balance |
Balance |
Balance |
Table 2. Typical mechanical properties for 304 stainless steel sheet
Grade |
304 |
304L |
304H |
Tensile Strength (MPa) |
520-720 |
500-6070 |
520-720 |
Compression Strength (MPa) |
210 |
- |
- |
Proof Stress 0.2% (MPa) |
210 |
200 |
210 |
Elongation A5 (%) |
45 Min |
45 Min |
40 Min |
Hardness Rockwell B |
92 |
- |
- |
Table 3. Typical physical properties for 304 stainless steel sheet
Property |
Value |
Density |
8.00 g/cm3 |
Melting Point |
1450°C |
Modulus of Elasticity |
193 GPa |
Electrical Resistivity |
0.072x10-6 Ù.m |
Thermal Conductivity |
16.2 W/m.K |
Thermal Expansion |
17.2x10-6 /K |
1. Port of Loading: Qingdao/Tianjin/Shanghai, China |
|
2. Standard export sea-worthy package |
|
A. Big OD:in bulk |
|
B. Small OD:packed by steel strips |
|
C. Woven cloth with 7 slates |
|
D.According to your deep. |
|
3.Inner size of contailer is as flows: |
|
20 ft GP:5.8m(length)*2.13m(width)*2.18m(height)about 24-26CBM |
|
40 ft GP:11.8M(length)*2.13m(width)*2.72m(height)about69CBM |
Our Services
Our service include
Process service : cutting , bending , surface treatment, embossing , packing.
Shipping service: our own shipping agent, the shipment can be start very fast, and the price is low.
Sample servce : for the requiement of the client, we can provide the sample for free.
Other service: we welcome friend from world wide to come to visit our company, we hope to build long term business with you.
Special requirement of products can be done.
Our company is a large storage company that located in Wuxi city, where is the largest stainless steel products center in China.Our main products is stainless steel sheet, stainless steel plate, stainless steel pipes, stainless stee bars(channel, angle, round, hex), steel plate, steel round bar, galvanized steel coils. etc.
The main material of our products is: 200 series ,300 series, 400 series ,904L ,duplex steel, carben steel.etc
We keeps about 8000 Ton products in stock, and the abilty we can supply ervey month is 3000 ton.
Our Promise:
(1) For every order, all the customer concern is supposed to be paid close attention,try our best
to enter the acme of perfection.
(2) For every customer,we believe our sercive is first,we hope to establish long-term cooperative
relationship under the basis of mutual benefit and win-win result
Related Products:
1. Stainless steel sheet/plate
2. Stainless steel coil/strip
3. Stainless steel tube/pipe (round,square, rectangle)
4. Stainless steel bar/rod (round,square, rectangle)
5. Stainless steel angle bar/rod
Material(Grade):
201, 202, 301, 301L, 302, 303, 304, 304L, 304N1, 309S, 310S, 316, 316L, 316Ti,316N, 317, 317L,321, 409L,410, 420, 430, 904L, etc.
IF YOU HAVE ANY QUESTIONS,PLEASE FEEL FREE TO CALL ME ANY TIME.ALL YOUR CONCERNS WILL BE RECEIVED OUR PROMPT ATTENTIONS!
Workshop Display
Contact Person: Mr. Gao Ben
Tel: +86-18068357371
Fax: 86-0510-88680060
