Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm

Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm
Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm

Large Image :  Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm

Product Details:
Place of Origin: China Jiangsu
Brand Name: ZHONGTIAN STEEL
Certification: SGS MTC ISO
Model Number: Gcr15 SAE52100
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Price: 0.65-1.15 USD/KG
Packaging Details: Export Packing
Delivery Time: 7 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000KGS

Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm

Description
OD: 6-300MM Length: 1000-12000mm
Surface: Black Bright Heat Treatment: Quenching And Temperature
Use: Bearings Mechanical Properties: As Standard
Highlight:

AISI 52100 Alloy Steel Round Bar

,

100Cr6 Alloy Steel Round Bar

,

SAE52100 Alloy Steel Round Bar

Gcr15 Alloy Steel Round Bar AISI 52100 SAE52100 Bearing Steel Round Rod OD 280mm

Product Description

GCr15 EN31 SAE52100 SUJ2 100Cr6 Alloy Structure Axle Bearing Steel Round Bar
1. Similar Standards
ChineseAmericanGermanJapanese
GBAISIDINJIS
GCr15SAE52100100Cr6/EN31SUJ2

2. Chemical Composition
GradesCSiMnPSCrMoCuNi
GCr15/521000.95-1.050.15-0.350.2-0.4≤0.027≤0.021.3-1.65≤0.1≤0.25≤0.3
100Cr60.95-1.050.15-0.350.25-0.45≤0.025≤0.0251.4-1.65≤0.08≤0.25≤0.3

3. Heat Treatment
QuenchingTempering
Heating Temperature/ºCCoolingHardness/HRCHeating Temperature/ºCCoolingHardness/HRC
830-850Oil62-65150-190Air58-62

4. Stock Size
Round BarDiameter16-280mm
Length4000-10000mm
Flat SteelThickness8-200mm
Length3000-4000mm




Product Overviews:
Steel productsroundDiameter 16mm - 1200mm
plate/flat /blockThickness 6mm-800mm
Width 20mm-1500mm
Heat treatmentNormalized ; Annealed ; Quenched and Tempered, pre-hardened
Surface ConditionBlack/ Peeled/ Polished/Machined /Grinded/Turned, Bright surface
Delivery Conditionhot rolled ; hot forged ; cold drawn
Quality guranteeEach heat ladle test chemistry,and finish products test chemistry; Ultrasonic test Sep 1921-84 class3 D/d, or ISO EN10228-4 class3. keep good grain sizes, do non-metalic test follow ASTM E45.
Payment TermsT/T;L/C;DP; DA
Delivery time30days
Trade TermsFOB; CFR; CIF




Our main products steel grades.

COLD WORK TOOL STEEL
GradeAISI /ASTMDIN (W.Nr)JISEN/ BSGB
DC53higher than D2 SKD11XW-5Cr8Mo2Vsi
D2D21.2379SKD11BD2CR12MO1V1
Cr12MoV    CR12MOV
D3D31.2080SKD1BD3CR12
O1O11.2510SKS3 9CRWMN
HMD5 HMD5  7CrSiMnMoV
5CrNiMoL655NiCrMoV6SKT4 5CrNiMo
52100521001.3505 EN31GCR15
HOT WORK TOOL STEEL
H13H131.2344/1.2342SKD61/DAC84074CR5MOSIV1
FDAC 1.2347FDAC FDAC
H11H111.2343SKD6 H11
3Cr2W8VH211.2581/ X30WCrV93SKD5BH213CR2W8V
PLASTIC MOULD STEEL
P20P201.2311HPM7/PX886183CR2MO
718P20+NI1.2738PX4/PX57183CR2NIMO
S1364201.2083S-STARS1364CR13
NAK80P21 /P20+S1.2312NAK80 15NI3MN
HIGH SPEED STEEL
M2M2 SKH51 W6MO5CR4V2
M42M42S2-10-1-8SKH59 W2MO9CR4VCO8

ALLOY STRUCTURE STEEL
GradeAISI /ASTMDIN (W.Nr)JISEN/ BSGB
512051201.7027 /21Cr4SCr420 20Cr
530M40 /5140530M40 /51401.7035 /41Cr4SCr440 40Cr
51455145 Scr445 45CR4
411841181.7243 /18CrMo4SCM418 / SCM420 20CrMo
413541301.7218 /25CrMo4SCM430708A25/ 708M2530CrMo
414041401.7225 /42CrMo4SCM440EN19/ 709M4042CrMo
434043401.6582/ 34CrNiMo6SNCM 439/ SNCM8EN24/ 817M4040CrNi2Mo
862086201.6523/ 21NiCrMo2SNCM220805M2020CrNiMo
CARBON STEEL
201020C22. CK22S20CEN3B /070M2020
351035C35.CK35S35C 35
451045C45.CK45S45CEN8D/C45E45
501050CK53S50CEN9/070M5550
Q355 S355J /ST52 EN14Q355
30Mn1030.1033 S30C 30Mn
30Mn2133030Mn5SMn433h 30Mn2
STAINLESS STEEL
steel grades: 304, 304L, 316, 316L, 321, 410 430, 431, 2205, 2304, 2507. F53, F55

Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm 0Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm 1
Gcr15 Alloy Steel Round Bar 100Cr6 AISI 52100 SAE52100 Bearing Steel Round Rod Quenching OD 280mm 2
