Product Details:
|
| Grade: | 304 | Application: | Engineering Structure |
|---|---|---|---|
| Type: | Equal,Equal And Unequal | Standard: | ASTM,AISI,DIN |
| Length: | 1-12m | Technique: | Hot Rolled |
| Product Name: | Asi Ss 316 Ss 304 304L Stainless Steel Equal Angle Bar | Dimensions: | 20*20mm*3mm-250x250x35mm |
| Shape: | Equilateral Angle Bar | Package: | Standard Sea-worthy Packing |
Stainless steel Angle steel is a long steel bar with vertical angles on both sides, and its specification is expressed by the millimeter number of side width × side width × side thickness.
| Product Name | Flat / Angle / Round / Channel Steel Bar |
| Standard | AISI, ASTM, BS, DIN, GB, JIS, YB/T4212-2010,etc. |
| Steel Grade | 201,202,303,303Cu,304,304L,316,316L,310S,316Ti,321,430,904L,Q235/Q345/A36/ SS400/STK400/STK500,etc. |
| Application | hoop iron/frame structure/escalator/mold steel/construction, etc. |
| Delivery Time | 7 to 15 days after the receipt of 30% deposit or as the order quantity. |
| Shipping | 1) Shipping by containers 2) Shipping by bulk ship 3) LCL(Less than container load) |
| Surface | Bright(polished), pickled, black |
| Technique | Forged/Hot Rolled/Cold Drawn/Peeled |
| Category | 1.Round bar |
| 1)Hot rolled black bar: (5-400)x6000mm or according to your requests. | |
| 2)Acid round bar: (5-400)x6000mm or according to your requests. | |
| 3)Cold drawn bright bar: (1-20)x6000mm or according to your requests. | |
| 4)Polishing round bar: (5-400)x6000mm or according to your requests. | |
| 2.Angle bar | |
| 1)Hot rolled angle bar: (16-200)x(16-200)x(3-18)x(3000-9000)mm or according to your requests | |
| 2)Acid angle bar: (16-200)x(16-200)x(3-18)x(3000-9000)mm or according to your requests. | |
| 3)Cold drawn angle bar: (16-200)x(16-200)x(1-3)x(3000-9000)mm or according to your requests. | |
| 3. Flat bar | |
| 1)Hot rolled flat bar: (3-30)*(10-200mm)*6000mm or according to your requests. | |
| 2)Cold drawn flat bar: (1-3)*(10-200mm)*6000mm or according to your requests. | |
| 4. Channel bar | |
| 1)Hot rolled channel bar: (5-100)x6000mm or according to your requests. | |
| 2)Acid channel bar: (5-100)x6000mm or according to your requests. | |
| 3)Cold drawn channel bar: (1-20)x6000mm or according to your requests | |
| 5.Hexagon bar Size 2mm~100mm |
|
Equal Angle Bar
|
|||||
|
Size
|
Theoretical Weight
|
Size
|
Theoretical Weight
|
Size
|
Theoretical Weight
|
|
mm
|
(kg/m)
|
mm
|
(kg/m)
|
mm
|
(kg/m)
|
|
25*3
|
1.124
|
70*6
|
6.406
|
100*16
|
23.257
|
|
25*4
|
1.459
|
70*7
|
7.398
|
110*8
|
13.532
|
|
30*3
|
1.373
|
70*8
|
8.373
|
110*10
|
16.69
|
|
30*4
|
1.786
|
75*5
|
5.818
|
110*12
|
19.782
|
|
40*3
|
1.852
|
75*6
|
6.905
|
110*14
|
22.809
|
|
40*4
|
2.422
|
75*7
|
7.976
|
125*8
|
15.504
|
|
40*5
|
2.967
|
75*8
|
9.03
|
125*10
|
19.133
|
|
50*3
|
2.332
|
75*10
|
11.089
|
125*12
|
22.696
|
|
50*4
|
3.059
|
80*6
|
7.736
|
125*14
|
26.193
|
|
50*5
|
3.77
|
80*8
|
9.658
|
140*10
|
21.488
|
|
50*6
|
4.465
|
80*10
|
11.874
|
140*12
|
25.522
|
|
60*5
|
4.57
|
90*8
|
10.946
|
140*14
|
29.49
|
|
60*6
|
5.42
|
90*10
|
13.476
|
160*12
|
29.391
|
|
63*4
|
3.907
|
90*12
|
15.94
|
160*14
|
33.987
|
|
63*5
|
4.822
|
100*8
|
12.276
|
160*16
|
38.518
|
|
63*6
|
5.721
|
100*10
|
15.12
|
160*18
|
48.63
|
|
63*8
|
7.7469
|
100*12
|
17.898
|
180*18
|
48.634
|
|
70*5
|
5.397
|
100*14
|
20.611
|
200*24
|
71.168
|
|
Unequal Angle Bar
|
|||||
|
Size (mm)
|
Theoretical Weight (kg/m)
|
Size (mm)
|
Theoretical Weight (kg/m)
|
Size (mm)
|
Theoretical Weight (kg/m)
|
|
25*16*3
|
0.912
|
75*50*5
|
5.339
|
110*70*10
|
13.476
|
|
32*20*3
|
1.717
|
75*50*6
|
4.808
|
125*80*8
|
12.551
|
|
40*25*3
|
1.484
|
70*50*7
|
5.699
|
125*80*10
|
15.474
|
|
40*25*4
|
1.936
|
75*50*8
|
7.431
|
125*80*12
|
18.33
|
|
40*28*3
|
1.687
|
80*50*6
|
5.935
|
140*90*8
|
14.16
|
|
40*28*4
|
2.203
|
90*56*6
|
6.717
|
140*90*10
|
17.475
|
|
45*30*4
|
2.251
|
90*56*7
|
7.756
|
140*90*12
|
20.724
|
|
50*32*3
|
1.908
|
90*56*8
|
8.779
|
160*100*10
|
19.872
|
|
50*32*4
|
2.494
|
100*63*6
|
7.55
|
160*100*12
|
23.592
|
|
56*36*3
|
2.153
|
100*63*7
|
8.722
|
160*100*14
|
27.247
|
|
56*36*4
|
2.818
|
100*63*8
|
9.878
|
180*110*10
|
22.273
|
|
56*36*5
|
3.466
|
100*63*10
|
12.142
|
180*110*12
|
26.464
|
|
63*40*4
|
3.185
|
100*80*7
|
9.656
|
180*110*14
|
30.589
|
|
63*40*5
|
3.92
|
100*80*8
|
10.946
|
200*125*12
|
29.761
|
|
63*40*6
|
4.638
|
100*80*10
|
13.476
|
200*125*14
|
34.436
|
|
63*40*7
|
5.339
|
110*70*8
|
10.946
|
|
|
