Product Details:
|
| Length: | Customer's Request,in Coil,500-12000MM | Grade: | 300 Series 316Ti |
|---|---|---|---|
| Application: | Construction | Type: | Plate |
| Standard: | ASTM | Width: | 600mm-2500mm |
| Surface: | NO.1 | Technique: | Hot Rolled |
| Thickness: | 3-100mm | Edge: | Mill Edge Slit Edge |
| Product Name | Stainless Steel Coil |
| Technique | Cold Rolled / Hot Rolled |
| Grade(ASTM UNS) | 201 202 301 304 304L 321 316 316L 317L 347H 309S 310S 904L S32205 2507 254SMOS 32760 253MA N08926 etc. |
| Grade (EN) | 1.4301, 1.4307, 1.4541, 1.4401, 1.4404 ,1.4571, 1.4438, 1.4539, 1.4547, 1.4529, 1.4562, 1.4410, 1.4878, 1.4845, 1.4828, 1.4876, 2.4858, 2.4819 |
| Thickness | 0.1-300mm or as required |
| Width | 1000, 1219, 1500, 2000, 2500, 3000mm or as required |
| Length | 1000, 1500, 2438, 3000, 5800, 6000, 9000, 12000mm or as required |
| Standard | ASTM JIS AISI GB DIN EN |
| Surface Finished | BA, 2B, NO.1, NO.4, 4K, HL, 8K, Checkered |
| Certification | CE, ISO, SGS, BV |
| Edge | Mill Edge / Slit Edge |
| Quality | SGS Inspection |
| Main market | Asia/ Europe/ South America/ Africa/ North Americal |
| Delivery time | Within 5-10 Working Days |
| Port of Loading | Shanghai/ Tianjin/ Qingdao Port, China |
| Price Terms | CIF/ CFR/ FOB/ EX-WORK |
| Export Packing | Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package |
| Supply Ability | 5000 Tons per Month |
| Payment Terms | T/T L/C and Western Union etc. |
| Application | Interior/exterior/architectural/bathroom decoration, elevator decoration, hotel decoration, kitchen equipment, ceiling, cabinet, kitchen sink, advertising nameplate etc. |
Mittel Was established in 2014 and is located inChina. 500 workers, 10000 square meters workshop, 15 years experience, 3 years' vendor of global market, ISO& CE certificated, with 10 production lines and annual output 50,000 tons.
316Ti stainless steel contains a small amount of titanium element based on 316 Austenitic stainless steel, titanium content is typically around 0.5%, and adding the titanium can stabilize the structure of the 316 at temperatures over 800°C. it prevents carbide precipitation at the grain boundaries and protects the metal from corrosion. The main advantage of 316Ti is that it can be held at higher temperatures for a longer period without sensitization (precipitation) occurring.
316Ti stainless steel is a derivate of 316 stainless steel and retains physical and mechanical properties similar to standard grades of 316.
The chemical composition of stainless steel 316H is generally composed of 16 to 18% chromium, 10 to 14% nickel, 2 to 3% molybdenum, and the minimum amount of titanium is 5 x (C + N), the maximum amount is 0.70%, titanium is strong carbide and nitride former, which helps prevent chromium from being consumed.
| C | Mn | P | S | Si | Ni | Cr | Mo | Ti | N | Fe | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 316Ti | 0.08 | 2.00 | 0.045 | 0.030 | 1.0 | 10-14 | 16-18 | 2-3 | 5x(C+N)-0.7 | 0.1 | Balance |
| Tensile Strength(Mpa) | Yield Point(Mpa) | Elongation(%) | Hardness, HRB | |
|---|---|---|---|---|
| 316Ti | 515 | 205 | 35 | 86 |
| AISI | UNS | DIN | EN | JIS | GB |
|---|---|---|---|---|---|
| 316Ti | S31635 | 1.4571 | X6CrNiMoTi17-12-2 | SUS316Ti | 1Cr18Ni12Mo2Ti |
| Density | Melting Point | Specific Heat | Thermal Conductivity | Coefficient Of Expansion | Electrical Resistivity | Elastic Modulus |
|---|---|---|---|---|---|---|
| G/Cm3 | (℃) | [J/(Kg·K)] 0~100 ℃ | [W/(M·K)] 100 ℃ | (10 – 6/K) 0~100 ℃ | NΩ.M | KN/Mm2 |
| 7.99 | 1398~1427 | 500 | 16.3 | 16.6 | 720 | 193 |
316Ti stainless steel has excellent corrosion resistance due to Titanium and Molybdenum element addition, It can withstand many organic and diluted mineral acids depending on the temperature and concentration of the solution. 316Ti may suffer from uniform corrosion in strong mineral acids, like hot concentrated nitric acid, or hot strong alkaline solutions.
Due to its titanium content, the risk of sensitization for intergranular corrosion is strongly reduced when compared to other austenitic chromium-nickel standards grades with normal carbon content.
316Ti is prone to chloride-induced stress corrosion (SCC) cracking at temperatures over about 50 °C depending on the applied stress and the chloride concentration in the environment. Prior cold deformation of the structure under load increases the risk of stress corrosion cracking.
316Ti stainless is a single-phase austenitic (face-centered cubic) stainless steel at all temperatures up to the melting point. Solution treatment or annealing can be done by rapid cooling after heating to 1900- 2150°F (1040-1175°C).
The alloy can not be hardened by heat treatment. The alloy is nonmagnetic in the annealed condition.
Our company is a set of production, processing, trade, sales in one of the large enterprises. We specialize in Alloy steel, Stainless Steel Sheets/ Plates/Coils/Strips/Pipes /Tubes/Rod/Bar, Galvanized Coil/ Sheet, Aluminum Coil/Sheet, Carbon Steel Coil/Sheet, etc with remarkable quality and best prices.
Q1. What are your company's main products ?
A1: Our main products are alloy materials, stainless steel, carbon steel, galvanized steel, aluminium products, etc.
