Product Details:
|
| Steel Grade: | Alloy Steel | Alloy Or Not: | Is Alloy |
|---|---|---|---|
| Technique: | Hot Rolled,Forged,Cold Drawn | Application: | Structural Steel Bar,Die Steel Bar,Tool Steel Bar |
| Type: | Alloy Steel Bar | Standard: | ASTM,DIN,GB,AISI,JIS |
| Shape: | Round | Length: | 1--12m |
| Surface: | Black Or Bright,Polished | Surface Treatment: | Black/Peeling/Polishing/Machined |
| Diameter: | 6-350mm | Delivery Condition: | Annealed |
| Dimensions: | 10mm~800mm | Heat Treatment: | Normalized +Annealed +Quenched + Tempered |
| High Light: | DIN 1.6511 Steel Round Bar,Alloy Hot Rolled Steel Bar,Alloy Steel Bar 55mm |
||
Hot rolled / forged 1.6582 4340 40CrNiMoA 34CrNiMo6 Alloy Steel Rod for tools
1.6582 4340 40CrNiMoA 34CrNiMo6 Alloy Steel Rod
Similar Grade
| GB | AISI | DIN | JIS | EN | TOCT | ISO | ||
| 40CrNiMoA | 4340 | 1.6582 | SNCM439 | 41NiCrMo 7-3-2 | 40XH2MA (40XHMA) |
36CrNiMo4 | ||
Specification of 4340 steel rod
| Diameter/Thikness(mm) | Width(mm) | Length(mm) | |
| Round Bar | 16-600 | / | 3000-6000 |
| Plate | 16-200 | 200-800 | 3000-6000 |
| The specification can be customized. | |||
Chemical compositons
| C | Si | Mn | P | S | Cr | Ni | Mo | |
| 40CrNiMo | 0.37-0.44 % | 0.17-0.37 % | 0.50-0.80 % | ≤0.025% | ≤0.025% | 0.60-0.90% | 1.25-1.65% | 0.15-0.25% |
| 4340 | 0.38-0.43 | 0.15-0.35 | 0.60-0.80 | ≤0.035 | ≤0.040 | 0.70-0.90 | 1.65-2.00 | 0.20-0.30 |
Features of 4340 steel rod
1, chromium molybdenum alloy steel;
2, high strength and toughness;
3, good stability of hardenability and anti-overheating;
4, good high tensile strength with shock resistance.
Typical applications
1, heavy machinery and high-load of shaft;
2, rotor shaft and blades;
3, special performance requirements of the vital parts after nitriding treatment.
Packing
20ft: GW 27T; (5.80mX2.13mX2.18m)
40ft: GW 27T; (11.8mX2.13mX2.18m)
Delivery time
For abundant stock, 15-20 days.For customized products, 30-50 days.
We have full set of equipement (sawing machine/grinding/polishing machine) to make customer's specification.
| STANDARD/GRADE of steel | Flat Bar Size(mm) | Round bar Size(mm) | Technics | ||||||
| DIN | AISM | JIS | GB(China) | Thickness | Width | Length | Diameter | Length | |
| 1.121 | SAE1050 | S50C | 50# | 10-450 | 155-2200 | 2000-12000 | Forged, Hot Rolled | ||
| 1.2311 | P20 | PDS-3 | 3Cr2Mo | 10-460 | 155-2200 | 2000-10000 | 20-200 | 2000-6000 | |
| 1.2738 | P20+Ni | - | 3Cr2NiMnMo | 21-300 | 155-2200 | 2000-8000 | 20-200 | 2000-6000 | |
| 1.2379 | D2 | SKD10 | SKD10 | 10-200 | 155-810 | 2000-6000 | 14-80 | 3000-6000 | |
| 1.2080 | D3 | SKD1 | 3Cr2Mo | 10-200 | 155-810 | 2000-6000 | 20-200 | 3000-6000 | |
| 1.2083 | 420 | - | 4Cr13 | 10-500 | 155-1200 | 2000-6000 | 12-300 | 3000-6000 | |
| 1.2344 | H13 | SKD61 | 4Cr5MoSiV1 | 10-500 | 155-1600 | 2000-6000 | 16-400 | 3000-6000 | |
| 1.2510 | O1 | SKS3 | 9CrWMn | 10-200 | 155-810 | 2000-6000 | 20-200 | 3000-6000 | |
| 1.7225 | SAE4140 | SCM440 | 42CrMo | 10-280 | 155-2200 | 2000-6000 | 16-450 | 3000-6000 | |
About Us
we are a professional special steel company, which specializing in this line in China since 2005. Our main products are Plastic Mould Steel, Hot Work Mould Steel, Cold Work Mould Steel, Alloy Structural Steel, Tool Steel, Stainless Steel, Carbon Steel and Forged Block.
To ensure provide high quality products to customers, we have close cooperation with many Chinese first class special steel enterprises, including Baosteel Group, Dongbei Special Steel, Changcheng Special Steel, Hongsheng Heavy Industry, Xingcheng Special Steel and Daye Special Steel.
