ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler

Certification
China JIANGSU MITTEL STEEL INDUSTRIAL LIMITED certification
China JIANGSU MITTEL STEEL INDUSTRIAL LIMITED certification
Customer Reviews
this is the second order l buy this company ,quality is very good ,same as europure quality .we will go on ccooperate with this company .

—— Andrew Greg - Turkey

200 ton Stainless steel sheet is arrived on 10th Oct 2014 , the quality is very good.,deliver time is very fast It's very lucky we find this factory

—— Mechile Kilar Chard - Brazial

We Have Cooperate With this Factory Many Years , Everything Goes Very Well.l Like This Factory !

—— Tony Hilton - Poland

This is Our Thrid Time Buy from Mittel,Quality is Very Goods ,We Are Glad to Find This Reliable Factory

—— Natalya Ugay-Russia

Quality is very good and delivery time very fast ,we want to do long terms business with this company

—— Pongpol Pluemsati-Thailand

I'm Online Chat Now

ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler

ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler
ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler

Large Image :  ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler

Product Details:
Place of Origin: China
Brand Name: TISCO ZPSS BAO STEEL
Certification: SGS ISO MTC
Model Number: S30408
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Price: 2.66 USD/KG
Packaging Details: Wodden Box
Delivery Time: 7 Working Days
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler

Description
Material: Stainless Steel,SUS304 Usage Condition: FLOOR INDUSTRIAL
Used With: Flower/Green Plant Color: Customized
Width: 1000mm 1219mm 1500 1800mm 2000-3500mm Shape: Flat Plate
Thickness: 1.5-100 Mm Or Customized
High Light:

Customized BA Stainless Steel Flat Plate

,

S30408 Stainless Steel Plate 2000mm

,

ASTM A240 Stainless Steel Plate TP304



Hot Rolled ASTM A240 TP304 S30408 Stainless Steel Plate 2000mm Width Used For Boiler



General Properties

Alloy 304 series stainless steel austenitic, which has a minimum of 18% chromium and 8% nickel. Type 304 has a maximum carbon of 0.08% . It is the standard “18/8 stainless” that is commonly found in pans and cooking tools. Alloy 304 is the most versatile and widely used alloy in the stainless steel family. Ideal for a wide variety of home and commercial applications, Alloy 304 exhibits excellent corrosion resistance and has a high ease of fabrication, outstanding formability. The austenitic stainless steels are also considered to be the most weldable of the high-alloy steels and can be welded by all fusion and resistance welding processes.

Specifications: UNS S30400

Alloy 304 Stainless Steel is used in a wide variety of home and commercial applications, including:

  • Kitchen benches, sinks, troughs, equipment, and appliances
  • Chemical containers, including for transport
  • Food processing equipment, particularly in beer brewing, milk processing, and wine making
  • Heat exchangers
  • Architectural trim and molding
  • Woven or welded screens for mining, quarrying & water filtration
  • Automotive and aerospace structural use
  • Nuts, bolts, screws, and other fasteners in the marine environment
  • Construction material in large buildings
  • Dyeing industry

Standards:

  • ASTM/ASME: UNS S30408 / S30403
  • EURONORM: 1.4301 / 1.4303
  • AFNOR: Z5 CN 18.09 / Z2 CN 18.10
  • DIN: X5 CrNi 18 10 / X2 CrNi 19 11

Corrosion Resistance:

  • Resistance to moderately aggressive organic acids is a result of the 9 to 11% nickel that the 304 alloys contain.
  • Resistance to corrosion in oxidizing environments is a result of the 18 to 19% chromium that the 304 alloys contain.
  • The 304, 304L, and 304H may be considered to perform uniformly in most corrosive environments.

Heat Resistance:

  • Continuous use of 304 in the 800-1580°F range is not recommended if subsequent aqueous corrosion resistance is important.
  • Good oxidation resistance in intermittent service to 1600°F and in continuous service to 1690°F.

1.Chemical Composition and Mechanical Properties(In Quenched & Tempered State):

Chemical Composition



Mechanical Properties(In Quenched & Tempered State)
C ≤0.08 Tensile strength(MPA) ≥520
Si ≤1.00 Yield strength (MPA) ≥205
Mn



≤2.00

Elongation(δ5/%) ≥ 40
Ni 8.00-11.00 Reduction in Area (ψ/%) ≥ 60
Cr 18.00-20.00 Impact (J) --
P ≤0.030



Hardness



Delivery hardness:≤187HB



S ≤0.030



2.Product Application Areas:

Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical

industry,electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,

transportation, and medical instruments, etc.



3.Similar steel grade & equivalent steel materials:



USA Japanese Gemany British France International Chinese
ASTM&AISI&SAE JIS EN DIN EN BS EN NF ISO GB
304 SUS304 1.4301 1.4301 1.4301 ------ S30408



Properties of 304 Alloy

Welding Characteristics:

Excellent welding properties; post-weld annealing is not required when welding thin sections. Two important considerations in producing weld joints in the austenitic stainless steels are:

  1. avoidance of cracking
  2. preservation of corrosion resistance

Processing – Hot Forming:

  • To forge, heat uniformity to 2100 / 2300 °F
  • Do not forge below 1700 °F
  • Forging can be air cooled without danger of cracking

Processing – Cold Forming:

  • Its austenitic structure allows it to be deep-drawn without intermediate annealing, Making this the stainless steel grade of choice in the manufacturing of sinks, hollow-ware and saucepans.
  • These grades work harden rapidly. To relieve stresses produced in severe forming or spinning, parts should be full annealed or stress relief annealed as soon as possible after forming.

Machinability:

  • The use of chip breakers is advised since the chips can be stringy. Stainless steel work harden rapidly, heavy positive feeds, sharp tooling, and a rigid set-up should be used.of cut below the work-hardened layer resulting from the previous passes.

 ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler 0ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler 1ASTM A240 BA Stainless Steel Plate TP304 S30408 2000mm Width For Boiler 2
