AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring

AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring
AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring

Large Image :  AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring

Product Details:
Place of Origin: China(mainland)
Brand Name: BAOSTEEL ANSTEEL SHOUSTEEL
Certification: ISO SGS
Model Number: 40Cr / 5140 / SCr440 / 41Cr4 / 1.7035
Payment & Shipping Terms:
Minimum Order Quantity: 5 ton
Price: 600-800 USD/Ton
Packaging Details: standard export seaworthy packing or as required
Delivery Time: 5-8 working days
Supply Ability: 500 ton/month

AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring

Description
Name: Alloy Steel Plate Technique: Cold Rolled / Hot Rolled
Width: 1500-2500mm Length: 6000-13000mm
Thickness: 3-120mm Application: Coiled Spring And Leaf Spring
High Light:

High Tenacity Carbon Alloy Stainless Plate

,

3.0 mm Alloy Steel Plate

,

Alloy Steel Plate For Leaf Spring

AISI 5140 Alloy Steel Plate / Carbon Steel Plate Thickness 3.0 - 120mm Custom Cutting Steel Plate



Products Name Steel Plate
Type Carbon Steel Plate, Alloy Steel Plate, Special Steel Plate
Thickness Range 3.0 - 150mm
Width Range 1000 - 2500mm as request
Length Range Within 12m
Brand BAOSTEEL, XINGCHENG,HBIS,BENSTEEL,TANGSHAN,HANSTEEL
Conpany Type Factory and storage
MOQ 1 Ton
Grade as following
Standard ASTM GB JIS EN


Grade of our steel plate (ASTM Grade as Guide)



Structural Steel A283,A36,ABS Grade A, Grade B, Grade ADH36, Grade DH36, and Grade EH36,A514 T-1,A572 GR 50:
HSLA Structural Steel A588,A656 GR80,A690
Pressure vessel Steel A285 GR C, A515 GR 70,A516 GR 70,SA537
Abrasion resistant steel AR360,AR400,AR450,AR500
Alloy Steel 5130,5140,5150,4130,4140
Product introduction

What is AISI 5140 steel ?

ASTM grade 5140 is one structural alloy steel grade in ASTM A29 standard for general application. 5140 steel plate is widely used in low and moderately stressed parts for vehicles, engines and machines where hard, wear resisting surface is needed. Gnee is professional 5140 plate & round bar supplier and we keep wide size range for 5140 plate in stock for immediate shipment. Contact us for any AISI 5140 plate material request and best 5140 grade steel price.

Competitive Advantage for AISI 5140 material steel plate in Otai:

  • Available in stock for immediate shipment
  • High strength,
  • High tenacity
  • Good hardenability
  • High resistance to thermal properties.
  • Competitive price

1. Supply Range of AISI/ASTM 5140

Round Bar: diameter 20mm – 300mm

Steel Plate and Steel Block: thickness 10-200mm x width 300-2000mm

  • 10-80mm thickness 5140 plate are available all the time in stock,
  • 90-200mm thickness plate to be newly production in 15-30 days lead time.

Surface Finish: Black Surface, Milled Surface or Polished Surface as per given requirements.

2. Relevant AISI 5140 Specification and Equivalent Steel Grades
Country USA German Japan
Standard ASTM/AISI A29 EN 10083-3 JIS G4053
Grades 5140 41Cr4 SCr440

3. ASTM 5140 Material Chemical Composition and Equivalent

Standard Grade/Steel Number C Mn P S Si Cr Ni
ASTM A29 5140 0.38-0.43 0.70-0.90 ≤0.035 ≤0.040 0.15-0.35 0.70-0.90
EN 10083-3 41Cr4 / 1.7035 0.38-0.45 0.60-0.90 ≤0.025 ≤0.035 ≤0.40 0.90-1.20
JIS G4053 SCr440 0.38-0.43 0.60-0.90 ≤0.030 ≤0.030 0.15-0.35 0.90-1.20 ≤0.25

4. AISI 5140 Steel Properties
Property Value in metric unit Value in US unit
Density 7.872 *10³ kg/m³ 491.4 lb/ft³
Modulus of elasticity 205 GPa 29700 ksi
Thermal expansion (20 ºC) 12.6*10-6 ºCˉ¹ 7.00*10-6 in/(in* ºF)
Specific heat capacity 452 J/(kg*K) 0.108 BTU/(lb*ºF)
Thermal conductivity 44.7 W/(m*K) 310 BTU*in/(hr*ft²*ºF)
Electric resistivity 2.28*10-7 Ohm*m 2.28*10-5 Ohm*cm
Tensile strength (annealed) 572 MPa 83000 psi
Yield strength (annealed) 293 MPa 42500 psi
Elongation (annealed) 29 % 29 %
Hardness (annealed) 85 RB 85 RB
Tensile strength (normalized) 793 MPa 115000 psi
Yield strength (normalized) 472 MPa 68500 psi
Elongation (normalized) 23 % 23 %
Hardness (normalized) 98 RB 98 RB
5. Forging of 5140 Alloy Steel

Hot forming temperature: 1050-850℃.

6. ASTM 5140 Steel Heat Treat
  • Soft Annealing

Heat to 680-720℃, cool slowly. This will produce a maximum 5140 hardness of 241HB (Brinell hardness).

  • Noramlizing of steel grade 5140

Temperature: 840-880℃.

  • Hardening of 5140 forged steel

Harden from a temperature of 820-850, 830-860℃ followed by water or oil quenching.

  • Tempering of SAE 5140 material

Tempering temperature: 540-680℃.

7. Applications of AISI Grade 5140

AISI 5140 steel can be used for low and moderately stressed parts for vehicles, engines and machines where hard, wear resisting surface is needed. Hardness as surface hardened about 54 HRC. SAE 5140 steels can also be for marine engineering industry, chemical processing plants, boiler & pressure vessels, nuclear power plants etc.

If you have queries about the 5140 specs, or any questions about the 5140 vs 4130, 5140 vs 4340 etc, please contact us for technical support any time.





AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring 0AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring 1AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring 2AISI 5140 High Tenacity Carbon Alloy Steel Plate Thickness 3.0mm For Leaf Spring 3
