Product Details:
|
| Certification: | CE, ISO, BV | Stock: | Always In Stock |
|---|---|---|---|
| Product Name: | 316LN Stainless Steel Plate | Surface: | 2B NO.1 8K |
| Technical: | Cold Rolled | Length: | 1000mm-6000mm |
| Width: | 1000mm, 1219mm, 1500mm 2000mm | Thickness: | 0.4 - 40.0mm |
| Brand: | Bao Steel, TISCO | MOQ: | 2 Tons |
| Payment Term: | T/T Or L/C | Price Term: | FOB, CFR, CIF |
| High Light: | TISCO laser cutting stainless steel plate,40.0mm laser cutting stainless steel plate,1.4571 316ti stainless steel sheet |
||
|
Commodity |
316Ti Stainless Steel Plate |
|
Grade |
201,202,304,304L,316,316L,316LN,316Ti, 310S,309S,321,301,310,410,420,430,904L |
|
Brand |
TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
|
Certification |
SGS, BV, IQI, TUV, ISO, etc |
|
Thickness |
0.4mm-40mm |
|
Width |
1000,1219,1250,1500mm, or as your requirements |
|
Length |
2000,2438,2500,3000,6000mm, or as your requirements |
|
Surface |
No.1, 2B, BA, 8K Mirror, Hairline, Satin, Embossed, Brush, No.4, HL, Matt, PVC film, Laser film |
|
Standard |
ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME, etc |
|
Delivery time |
5-7 days after confirming the order |
|
MOQ |
1 Ton |
|
Advantages |
Showing the splendor of your quality, wearresistant as well. |
316 quality stainless steel is a material quality obtained by adding molybdenum and more nickel into 304 quality stainless steel. Thanks to this content, the corrosion resistance of 316 quality materials is very good even in harsh conditions (seawater, acidic liquids, etc.). Furthermore, the ultimate strength of 316 quality materials is much higher than that of 304 quality materials. 316Ti is the addition of titanium into 316 quality stainless steel. If the material is exposed to high temperatures from 550 to 800 ° C for a long time, use 316Ti (1.4571) grade stainless steel. 316Ti stainless steels contain low amounts of titanium. This rate is usually 0.5%. 316Ti grade stainless steels have a longer life time than 304 or 316 stainless steel grades.
| Chemical Composition | |||||||||
| Quality | C | Mn | PA | S | Si | Cr | NU | B.C | T |
| 316Ti (1.4571) | 0.08max | 2.0 | 0045 | 0030 | 1.0 | Between 16.0-18.0 | Between 10.0 and 14.0 | Between 2.0-3.0 | 0.70 max |
| Mechanical Properties at Room Temperature | |
| Quality | 316Ti (1.4571) X6CrNiMoTi17-12-2 |
| Tensile strength | 485 MPa |
| Yield strength, (0.2%) | 170 MPa |
| Hardness, Rockwell (HB) | - |
| Summary of Quality Characteristics | |
| 316Ti stainless is numbered 1.4571 quality stainless according to EN standard. | |
| 316Ti grade stainless is also called X6CrNiMo17-12-2 according to EN standard. | |
| 316Ti quality stainless is an increasingly high quality stainless steel grade, but its use is not as common as 316 and 316L grade stainless. | |
| This quality is of the stainless steel grade. | |
| The weldability of this stainless steel quality is good but not suitable for pounding. | |
| Stainless steel of this quality does not attract magnets and has a high corrosion resistance. | |
| 316Ti stainless is a stainless steel grade which is resistant to friction due to the titanium it contains. | |
| Corrosion resistance of 316Ti quality stainless steel is better than 304 quality stainless steel. |
