Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm

Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm
Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm

Large Image :  Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm

Product Details:
Place of Origin: China
Brand Name: MITTEL
Certification: SGS ISO MTC
Model Number: 410 12Cr13
Payment & Shipping Terms:
Minimum Order Quantity: 200KGS
Price: 2.15 USD/KG
Packaging Details: Wodden Pallet
Delivery Time: 14 Days after receive the deposit
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm

Description
Grade: 410 Application: Construction,Industry,Steel Grating,ships Building Industry,rudder Shaft
Standard: ASTM,DIN,AISI,JIS Shape: Falt Plate
Type: Flat Length: 5.8-12m
Technique: Hot Rolled Surface: BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D
Width: 12-300mm,10mm~500mm,20~2300mm Thickness: 2mm~100mm
Price Term: CIF CFR FOB EX-WORK Stock: YES,In Stock
High Light:

ss 410 stainless steel flat bar

,

laser cutting stainless steel flat bar

,

ss 410 stainless flat bar





410 stainless steel properties

Type 410 SS is a hardenable, martensitic stainless steel. It combines the superior wear resistance of high carbon alloys with the excellent corrosion resistance of chromium stainless. It features high strength, heat resistance, and good ductility. Good corrosion resistance in mild atmospheres, steam and mild chemical environments make it well suited for highly stressed parts. This grade of 410 stainless steel is magnetic in both the annealed and hardened conditions.



Our 410 stainless steel materials are used in aerospace, automotive, petrochemical and medical applications. Grade 410 SS is also used in manufacturing of products like springs and fasteners, as it can be machined after tempering or annealing. For free machining applications that do not require the higher corrosion resistance of 410, consider our grade of 416 stainless instead.

410 stainless steel Standard Inventory Specifications

UNS S41000 AMS 5504 AMS 5613 (Chemistry only)
ASTM A 240 ASTM A 276 ASTM A 493
ASTM F 899 ASME SA 240 B50991B

410 stainless steel Chemical Composition



Element

Percent by Weight

C Carbon 0.15 max
Mn Manganese 1.00 max
Si Silicon 1.00 max
Cr Chromium 11.50 - 13.50
C Nickel 0.75 max
S Sulfur 0.03 max
P Phosphorus 0.04 max
410 Stainles Steel Physical Properties

The values reported below are typical for Type 410 alloy in the annealed condition.

  • Density: 0.276 lb/in3

  • Specific Gravity: 7.65

  • Melting Range: 2700-2790°F 1482-1532°C

  • Modulus of Elasticity: 29 x 106 psi (200 GPa)

410 stainless steel Coefficient of Thermal Expansion

Temperature Range

Coefficients

°C

°F

cm/cm/°C

in/in/°F

20-200 68-392 10.5 x10-6 5.9 x 10-6
20-600 68-1112 11.6 x 10-6 6.5 x 10-6

410 stainless steel Thermal Conductivity

Temperature Range

W/m·K

Btu/(hr · ft · °F)

°C

°F

100 212 (0.249) 14.4

410 stainless steel Specific Heat

  • .11 Btu/lb.·°F

410 stainless steel Electrical Resistivity

Temperature Range

microhm-cm

°C

°F

20 68 56

410 stainless steel Mechanical Properties and Yield Strength

Typical Annealed Properties

Hardening Response HRC

HRB

0.2% Offset
Yield Strength
Ksi (MPa)

Tensile Strength
Ksi (MPa)

Elongation, Percent in 2" (51 mm)

82-96 30 (205) - 42 (290) 65 (450) - 74 (510) 20 -34 38-45

410 stainless steel Common Trade Names

  • ATI 410 (™ Allegheny Technologies)

  • Alloy 410

  • AISI Type 410

410 stainless steel Common Applications

  • Aerospace structures

  • Automotive exhausts, manifolds and high temperature engine components

  • Medical instruments and devices

  • Petro-chemical applications

  • Cutlery, kitchen utensils

  • Flat springs

  • Hand tools

Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm 0Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm 1Ss 410 Stainless Steel Flat Bar Metal Plate Laser Cutting 12cr13 40*6*2000mm 2
