Product Details:
|
Certification: | CE, ISO, BV, SGS | Stock: | Always In Good Stock |
---|---|---|---|
Commodity: | 304LN/S30451 | Length: | 1000mm-6000mm |
Width: | 1000mm-2000mm | Thickness: | 0.6mm-30mm |
Standard: | ASTM, AISI, JIS, DIN, EN, GB | Mill Name: | BAO STEEL, TISCO, ZPSS |
Surface: | 2B, BA, 8K, NO.1 | Color: | Natural Color |
High Light: | 304ln stainless steel flat plate,astm a240 stainless steel flat plate,astm 0.6mm stainless steel plate |
304LN Stainless Steel Plate ASTM A240/240M-15 SS Plate 0.6 - 30.0mm
Specification of our products
Products name | 304LN stainless steel plate sheet |
Available thickness | 0.6 - 30.0 mm |
standard size | cold rolled sheet 0.6 - 3.0mm* 1219*2438mm |
hot rolled plate 3.0 - 30.0mm *1500*6000mm | |
Original finishing | cold rolled: 2B hot rolled : NO.1 |
Standard | ASTM A240/240M-17 |
Other products | Strips , bars , pipes.etc |
Other grade | 201 202 304 304L 309S 310S 316L 316Ti 321 347 410 420 430 441 443 444.etc |
Stainless steel grade 304 is the most commonly used stainless steel. Stainless steel grade 304LN is a nitrogen-strengthened version of stainless steel grade 304.
The following datasheet provides an overview of grade 304LN stainless steel.
The chemical composition of grade 304LN stainless steel is outlined in the following table.
Element | Content (%) |
---|---|
Chromium, Cr | 18-20 |
Nickel, Ni | 8-12 |
Manganese, Mn | 2 max |
Silicon, Si | 1 max |
Nitrogen, N | 0.1-0.16 |
Phosphorous, P | 0.045 max |
Carbon, C | 0.03 max |
Sulfur, S | 0.03 max |
Iron, Fe | Remainder |
The mechanical properties of grade 304LN stainless steel are displayed in the following table.
Properties | Metric | Imperial |
---|---|---|
Tensile strength | 515 MPa | 74694 psi |
Yield strength | 205 MPa | 29732 psi |
Elongation at break (in 50 mm) | 40% | 40% |
Hardness, Brinell | 217 | 217 |
Hardness, Rockwell B | 95 | 95 |
Equivalent materials to grade 304LN stainless steel are given below.
ASTM A182 | ASTM A213 | ASTM A269 | ASTM A312 | ASTM A376 |
ASTM A240 | ASTM A249 | ASTM A276 | ASTM A336 | ASTM A403 |
ASTM A193 (B8LN, B8LNA) | ASTM A194 (8LN, 8LNA) | ASTM A320 (B8LN, B8LNA) | ASTM A479 | ASTM A666 |
ASTM A688
|
ASTM A813
|
ASTM A814
|
DIN 1.4311
|
|
Grade 304LN stainless steel is widely used in the following applications:
