Product Details:
|
| Company Type: | Storage And Trading | Processing Technology: | Hot Rolled |
|---|---|---|---|
| Grade: | 317LN | Surface: | 2B BA NO.4 NO.1 Mirror 8K |
| Standard: | GB JIS ASTM AISI EN DIN | Port: | Shanghai |
| Thickness: | 0.5 - 30.0mm | ||
| High Light: | aisi 317l stainless steel plates,s31753 stainless steel plates,bv 0.5mm stainless steel plate |
||
ASTM A240 S31753 / 317LN Stainless Steel Plate 0.5 - 30.0mm SS Plate AISI317LN Stainless Steel Plate
Stainless steel 317LN is a nitrogen alloyed austenitic stainless steel having high nitrogen content than other austenitic stainless steels. It has higher yield and tensile strength than 317L. This low carbon grade steel provides resistance to sensitization during welding and thermal processes. Low carbon content in its composition makes the alloy resistant to inter granular corrosion. It also offers excellent corrosion resistance to organic, sulfuric and phosphoric acids.
The chemical composition of Grade 317LN stainless steel is outlined in the following table.
| Element | Content (%) |
|---|---|
| Iron, Fe | 63.43 |
| Chromium, Cr | 18.2 |
| Nickel, Ni | 14 |
| Molybdenum, Mo | 4.2 |
| Nitrogen, N | 0.15 |
| Carbon, C | 0.02 |
The mechanical properties of Grade 317LN stainless steel are displayed in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | ≥590 MPa | ≥85600 psi |
| Yield strength | ≥285 MPa | ≥41300 ksi |
| Modulus of elasticity | 200 GPa | 29000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poissons ratio | 0.299 | 0.299 |
| Elongation at break | ≥40% | ≥40% |
The properties of 317LN is similar to other conventional austenitic stainless steels, and can therefore, be fabricated in a manner similar to alloys 316L and 317L. Heat treatment of 317LN can be carried out at temperatures ranging from 1080 to1175°C (1975 to 2150°F) followed by rapid water quenching. This grade is not hardenable.
The following are some of the major applications of Grade 317LN stainless steel:
