Product Details:
|
| Steel Grade: | Ss400 A36 S45c Sae1045 42CrMo | Alloy Or Not: | Non-alloy |
|---|---|---|---|
| Technique: | Cold Drawn | Application: | Structural Steel Bar |
| Type: | Carbon Steel Bar | Standard: | ASTM,DIN,GB,AISI,JIS |
| Shape: | Round | Length: | 1--12m |
| Surface: | Black Or Bright | Dimensions: | Dia 8-60mm |
| Heat Treatment: | Normalized +Annealed +Quenched + Tempered | ||
| High Light: | S45C Cold Drawn Round Steel Rod,SAE1020 Cold Drawn Round Steel Rod,SAE1045 Cold Drawn Steel Round Bar |
||
s45c c45 sae1045 aisi1045 carbon steel is used for heat treating (quenching and tempering). Although it has only a fair response to conventional quenching, it is widely used where requirements are not too stringent. It is also used extensively in induction hardening applications. This is not normally considered a screw machine steel and is only fair for brazing and welding. However, it can be forged satisfactorily and is the most common shafting steel in the medium carbon range.
1. s45c c45 sae1045 aisi1045 Steel Grade
| GB | DIN | AISI/SAE | JIS |
| 45# | C45 (1.0503) CK45 (1.1191) CM45(1.1201) | AISI1045 SAE1045 | S45C |
2. s45c c45 sae1045 aisi1045 Steel Chemical Composition (%):
| C | SI | MN | S | P | CR |
| 0.42-0.48 | 0.15-0.35 | 0.60-0.90 | 0.035(MAX) | 0.035(MAX) | 0.30-0.40 |
3. s45c c45 sae1045 aisi1045 Steel Mechanical Properties after QT:
| Yield Strength(MPa) | Tensile Strength(MPa) | Elongation(%) | Reduction of area |
| 400(min) | 600(mIn) | 12%(min) | 35% |
4. s45c c45 sae1045 aisi1045 steel bar Size Range
| Commodity delivery condition | Dimensions |
| Hot rolled steel round bars | 10mm to 310mm |
| Hot rolled steel square bars | 16mm*16mm to 100mm*100mm |
| Hot rolled steel flat bars | (8mm to 60mm)*(20mm to 100mm) |
| Forged steel round bars | 200mm to 800mm |
| Forged steel square block | 200mm*200mm to 500mm*500mm |
| Forged steel flat block | (150mm to 500mm)*(200mm to 500mm) |
| Cold drawn steel round bar | 8mm to 150mm |
| cold drawn steel square bar | 10mm*10mm to 50mm*50mm |
| Cold drawn hexagonal steel bar | 14mm to 100mm |
| Hot rolled and peeled or turned steel bright bars | 20mm to 120mm |
5.Producing line:
s45c c45 sae1045 aisi1045 hot rolled steel round bar production line
1): Iron - hot metal pretreatment - Converter - Refining --VD / RH- - Continuous Casting - Hot Rolling (KOCKS) - heat --UT Check - Processing and Distribution Center
2): Electric Furnace - Refining --VD / RH- - Continuous Casting - Hot Rolling (KOCKS) - heat --UT Check - Processing and Distribution Center
6.FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
