Product Details:
|
| Application: | Construction | Width: | 1000-2000mm |
|---|---|---|---|
| Type: | Stainless Steel Sheet | Standard: | ASTM |
| Length: | 1000-6000mm Or Customer's Requirement | Grade: | 400 Series |
| Surface: | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D | Thickness: | 0.45-5mm |
| Edge: | Slit Edge,Mill Edge | Technique: | Cold Rolled Finish |
| Price Term: | CIF CFR FOB EX-WORK | ||
| High Light: | stainless steel metal sheet,stainless steel panels |
||
Finish BA cold rolled 430 stainless steel coils 0.3-1.2mm
Quick detail:
Description:430 stainless steel sheet in coils/430 Cold rolled stainless steel coils
Grade: SUS430 1.4016 S43000
Thickness: 0.3-1.2mm
Finish: BA
Width:1000 1030 1250 1550 1500
Standard: JIS EN ASTM AISI
Coil ID: 508/610mm
Paper Interleaved: Yes
Main Specification
| Description | 430 stainless steel sheet in coils/430 Cold rolled stainless steel coils/CR stainless steel sheet in coils |
| Grade | SUS430 1.4016 S43000 |
| Thickness | 0.3-3.0mm |
| Finish | 2B BA No.3 No.4 HL PE/PVC |
| Width | 1000-1550mm |
| Standard | JIS EN ASTM AISI |
| Coil ID | 508/610mm |
| Thickness tolerance | to be defined with customers |
| Q'ty tolerance | +/-10% on order quantity |
| Paper Interleaved | Yes |
| Country of Origin | made in China |
| Packaging | Seaworthy standard export package with pallet: |
| ·Paper interleaved | |
| ·Horizontal straps+vertical straps | |
| ·External metal or cardboad protection | |
| ·Pallet is including |
CHEMICAL COMPOSITION&Mechanical properties
| STANDARD | GRADE | CHEMICAL COMPOSITION(%) | ||||||
| C max | Si max | Mn max | P max | S max | Ni | Cr | ||
| JIS | SUS430* | 0.12 | 0.75 | 1.00 | 0.040 | 0.030 | - | 16.00~18.00 |
| GB | 1Cr17 | 0.12 | 1.0 | 1.00 | 0.040 | 0.030 | 0.75 | 16.00~18.00 |
| ASTM | S43000* | 0.12 | 1.0 | 1.00 | 0.040 | 0.030 | 0.75 | 16.00~18.00 |
| EN | 1.4016 | 0.08 | 1.0 | 1.00 | 0.040 | 0.015 | - | 16.00~18.00 |
| Mechanical properties | ||||||||
| Yield Strength | Tensile Strength | Elongation | Hardness | |||||
| (N/mm2) | (N/mm2) | (%) | HRB | HV | ||||
| ≥205 | ≥420 | ≥22 | ≤80 | ≤200 |
||||
